ECONOMY HIGH STRENGTH ROD ENDS HIGH MISALIGNMENT SERIES
Economical, two-piece CMX/CMXL rod ends have hard chrome ROD END
plated 52100 steel ball and heat treated alloy steel bodies. Designed for high misalignment applications, three-piece rod
(Available with a PTFE liner. Add a “T” to the end of the part end features a heat treated and hard chrome plated steel ball,
number.) chromate treated and zinc plated steel race, 4340 steel heat
RH LH Thread Hole Ult. Static treated and chromate treated body, and PTFE liner.
Part No. Part No. Size Size Radial Load RH LH Thread Hole Ult. Static
FKBCMX8 FKBCMXL8 1/2"-20 .500" 17,000 Part No. Part No. Size Size Radial Load
FKBCMX10-8 FKBCMXL10-8 5/8"-18 .500" 18,000 FKBHRSMX8T – 5/8"-18 .500" 23,703
FKBCMX10 FKBCMXL10 5/8"-18 .625" 18,000
FKBCMX12-10 FKBCMXL12-10 3/4"-16 .625" 25,000
FKBCMX-12 FKBCMXL-12 3/4"-16 .750" 25,000 HEAVY DUTY
SPHERICAL BEARINGS
PRECISION SERIES ROD ENDS Spherical bearings are offered in two-
JMX/JMXL three-piece rod ends are made of high strength (ball/race) and three-piece (ball/body/race)
alloy with 52100 hard chrome plated steel balls, heat treated designs. All include PTFE liners.
steel alloy bodies and races. (Rod ends are also available with B D W T O Ult. Static
a PTFE liner. Add a “T” to the end of the part number.) Part No. Description Dia. Dia. Width Width Dia. Radial Load
RH LH Thread Hole Ult. Static FKBHIN10T 3-Pc. .625" 1.3750" 1.200" .567" .856" 44,652
Part No. Part No. Size Size Radial Load High Misalignment Series
FKBJMX6 FKBJMXL6 3/8"-24 .375" 9,550 FKBFKS12T 2-Pc. Precision Series .750" 1.4375" .750" .593" .920" 78,000
FKBJMX7 FKBJMXL7 7/16"-20 .437" 10,290 FKBCOM12T 2-Pc. Commercial .750" 1.4375" .750" .593" .920" 31,920
FKBJMX8 FKBJMXL8 1/2"-20 .500" 16,242 FKBWSSX12T 2-Pc. Wide Series .750" 1.3750" .875" .630" .845" 37,000
FKBJMX10 FKBJMXL10 5/8"-18 .625" 17,959 FKBWSSX16T 2-Pc. Wide Series 1.000" 2.1250" 1.375" 1.005" 1.269" 104,000
FKBJMX12 FKBJMXL12 3/4"-16 .750" 28,090
BEARING CUPS
FOR SPHERICAL BEARINGS
EXTRA STRENGTH HEAVY DUTY
Manufactured from 4130 alloy steel, bearing cups are sold
SHANK ROD ENDS complete with snap ring.
RSM/RSML three-piece rod ends have extra strength, heavy Replacement
duty shanks with low carbon steel, chromate treated bodies, Part No. Description I.D. Width O.D. Snap Ring
hard chrome plated steel balls and heat treated steel alloy FKBCP12 Fits COM12, 1.4375" 1.000" 1.750" FKBSR12
races. RSMX/RSMXL rod ends have heat treated alloy steel FKS12, FKSSX12T
bodies. FKBCPW16 Fits AIN16, WSSX16T 2.1250" 1.500" 2.625" –
RH LH Thread Hole Ult. Static
Part No. Part No. Size Size Radial Load
FKBRSM8 FKBRSML8 5/8"-18 .500" 12,843
FKBRSMX8 FKBRSMXL8 5/8"-18 .500" 31,420 CLEVIS
FKBRSMX10-8T FKBRSMXL10-8T 3/4"-16 .500" 40,590 Low carbon steel clevis are chromate treated and zinc plated.
FKBRSMX10* – 3/4"-16 .625" 40,590 Part No. Bore Thread
* Also available PTFE lined by adding “T" to part number. FKBCV1 3/8" 5/8"-18
FKBCV5 3/8" 1/2"-20
ALUMINUM SERIES STEEL AND ALUMINUM
ROD ENDS JAM NUTS
Three-piece male rod ends are manufactured using black Thread Hex Steel Steel Alum. Alum.
anodized aluminum 7075-T6 bodies, heat treated and hard Size Size RH LH RH LH
chrome plated steel balls, and heat treated, chromate treated 5/16"-24 1/2" FKBSJNR05 FKBSJNL05 FKBAJNR05 FKBAJNL05
and zinc plated races. 3/8"-24 9/16" FKBSJNR06 FKBSJNL06 FKBAJNR06 FKBAJNL06
RH LH Thread Hole Ult. Static 7/16"-20 11/16" FKBSJNR07 FKBSJNL07 FKBAJNR07 FKBAJNL07
Part No. Part No. Size Size Radial Load 1/2"-20 3/4" FKBSJNR08 FKBSJNL08 FKBAJNR08 FKBAJNL08
FKBALRSM8B FKBALRSML8B 5/8"-18 .500" 14,880 5/8"-18 15/16" FKBSJNR10 FKBSJNL10 FKBAJNR10 FKBAJNL10
3/4"-16 1-1/8" FKBSJNR12 FKBSJNL12 FKBAJNR12 FKBAJNL12

FLO-MAX FUEL FILTER/WATER SEPARATOR SYSTEMS
Flo-Max filter systems flow up to 300 gallons per hour and use a high efficiency, 5 micron filtration and water separation element. Compact,
light billet aluminum housings use replaceable, spin-on filters to eliminate the chance of fuel system contamination. System has no housing
seals or gaskets to leak or swell. Choose systems with red, clear or black anodized housings.
Part No. Application Color Ports Size
FILRPM300 High Performance/Racing Red 1/2" NPT 4-1/4" H. x 3" W. x 3-3/4" D.
FILRPM350 High Performance/Racing Clear -6, -8 ORB 4-1/4" H. x 3" W. x 3-3/4" D.
FILRPM500 Racing/Marine Black -12 ORB 8" H. x 3-3/4" W. x 5" D. FILRPM500
