PRO SPORT 5-BOLT FLAPPER
SPECIALIZED FUEL CELLS JAZ315-105-03
Pro Sport Specialized cells use red or black Flapper mounts under 12-bolt bail handle fuel caps, seal-
powder coated, 20 gauge steel containers with ing the cap in the event of a rollover and reducing the chance
seamless, cross-linked polyethylene inner shells, of fuel leakage from the cap. Sold complete with necessary
D-ring bail handle cap assemblies, -10AN fuel hardware and instructions.
pickups, -8AN tip-over valve vents and -8AN return
fittings. Top pickup hose is routed to right rear corner.
Cells listed do not include safety foam.
Red Container Black Container
Description Size Part No. Part No. FUEL CELL COMPONENTS JAZ350-201-06
22-Gallon, 25" x 16-3/4" x 13-5/8" JAZ270-622-NF –
Top Feed Part No. Description
32-Gallon, 26-5/8" x 18-5/8" x 18-5/8" JAZ270-532-NF JAZ270-532-NF1 JAZ305-051-03 Aluminum Bat Wing Pick-Up, -8AN
Top Feed JAZ305-052-03 Aluminum Bat Wing Pick-Up, -10AN
JAZ315-030-03 Split Nut Ring, Allows Installation of Fast Fill Valves
FUEL CELL TIP-OVER VALVES JAZ834-008-11 JAZ340-025-03 JAZ345-250-03 And JAZ345-225-03
Replacement Cap for Pro Max Cell
Prevents fuel spillage in the event of a roll-over. JAZ340-200-06 Replacement Flush Mount Cap Only
Part No. Description JAZ340-300-09 Bail Handle Cap Only
JAZ834-006-11 -6AN Tip Over Valve JAZ345-225-03 45° Fast Fill Valve, 2-1/4" O.D., Requires JAZ315-030-03
JAZ834-008-11 -8AN Tip Over Valve JAZ350-201-06 Replacement Flush Mount Cap Assembly, 6-Bolt
JAZ834-206-06 -6AN External Tip Over Valve JAZ834-208-06 JAZ350-250-03 Fender Filler, Recessed With 2-1/2" Hose Nipple
JAZ834-208-06 -8AN External Tip Over Valve JAZ350-301-03 Bail Handle Cap and Filler Neck
JAZ360-222-11 Fuel Cell Foam Kit, 22-Gallon, 222 Series Cells
JAZ850-300-01 Bail Handle Cap Gasket
FAST FLOW FUEL CELL FITTINGS
Fully radiused, Fast Flow Fuel Cell Fittings include bulkhead nuts and poly FUEL FUNNELS
washers. Poly washers are also available separately. STANDARD TRIANGULAR
Fuel Cell Fitting Poly Washer
Size Part No. Part No. JAZ550-014-06
-6AN JAZ832-106-11 JAZ850-506-04 14" triangular shape allows easy filling against a bulk head. 3-step
-8AN JAZ832-108-11 JAZ850-508-04 spout may be cut off for different rates of flow. 17" long. Accepts filter
-10AN JAZ832-110-11 JAZ850-510-04 JAZ500-000-01.
-12AN JAZ832-112-11 JAZ850-512-04
-16AN JAZ832-116-11 JAZ850-516-04 LARGE TRIANGULAR
JAZ550-016-06
OVAL FILLER PLATE KIT 16" triangular funnel is similar to the stan dard funnel,
Oval, 6" x 10" black powder coated filler plate but with a larger capacity and a tapered spout for different flow
incorporates a -10AN pickup, -8AN vent and rates. 22" long. Accepts filter JAZ500-000-01.
return, tip-over valve and dipstick access.
Offered with D-ring cap or 45° fast fill valve. JAZ315-710-01
Part No. Description
JAZ315-610-01 Oval Filler Plate Kit, D-Ring Cap GO DEEP JAZ560-014-06
JAZ315-710-01 Oval Filler Plate Kit, 45° Fast Fill Valve
Ideal for automatic transmissions, 7" x 14" funnel has
12-BOLT FILL VALVE a built-in handle, anti-splash ring and 30" long, tapered
spout. Accepts filter JAZ500-000-01.
WITH CHECK VALVE FLAPPER
JAZ391-251-03
Designed to be retrofitted onto any standard, 12-hole
pattern cap assemblies, fill valve includes a 2-1/4"
diameter fill tube and twist-lock cap. A bolted-in FILTER INSERT JAZ500-000-01
plastic flapper provides rollover protection and
includes a -10AN tip-over valve vent fitting. 60-micron stainless steel screen is easily re moved
for cleaning. O-ring is set into a molded-in groove to
provide a tight seal. Fits above funnels.
FLAPPER/FILL VALVE
JAZ390-004-01 OVERFLOW CATCH CANS
IMCA accepted, cast aluminum fill Molded one-piece, one quart catch can has unique
valve features a spring-loaded flapper swivel elbow input and a lever handle petcock for
for roll-over protection so that it may draining. Easily mounted with two mold ed-in
be used to update existing fuel cells to meet 1/4"-20 threaded in serts.
current sanctioning body rules. Fill valve has popular JAZ 12-bolt pattern, and Black Clear Red Orange Blue
includes a steel bail handled cap. Part No. Part No. Part No. Part No. Part No.
JAZ600-025-01 JAZ600-025-05 JAZ600-025-06 JAZ600-025-07 JAZ600-025-11
Note: May be mounted using Allstar ALL14200 or ALL14201 brackets
