Page 471 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

BILLET ALUMINUM OIL COOLER/FILTER SANDWICH ADAPTER
REMOTE OIL FILTER MOUNTS MOR23693
Remote oil filter mount accepts Chevy style oil filter and offers more Adapter installs between filter pad on engine block
installation options. Black anodized, billet aluminum mount has two -12AN and spin-on oil filter, and includes provisions to plumb
inlets and three outlets, one -12AN and two 1/4" NPT. a remotely mounted oil cooler or accumulator. Billet
aluminum, black anodized finished adapter includes
-10AN pressure and return ports. Adapter, which has
3/4”-16 threads and a 2-5/8” O-ring, fits popular Ford,
Chrysler and other 4-/6-cylinder applications.

OIL COOLER/FILTER SANDWICH ADAPTER
FOR GM LS MOR23694
MOR23763 MOR23764
Part No. Description Billet aluminum adapter installs between spin-on oil
MOR23763 Remote Oil Filter Mount, Side Port Style filter and filter pad, providing connections for a remote
MOR23764 Remote Oil Filter Mount, Front Port Style oil cooler or accumulator. Adapter, which fits all ‘97-06
LS1, includes 13/16"-16 thread and -10AN ports.
MOR23750
REMOTE OIL FILTER MOUNTS OIL FILTER BYPASS MOR23770
Remote oil filter mounts for dry sump oil sys tems Oil Filter Bypass fits all small block Chevy V-8’s.
or wher ev er in stal la tions require a re mote mount ed For use with wet sump oil systems when re mote oil
oil filter. Cast alu mi num mounts are tapped for filters or coolers are used. Bypasses are cast from
1/2" NPT adapters and use spin-on type filters. aluminum with 1/2" NPT inlet and outlet.
Part No. Description Includes gaskets and fasteners.
Flow Direction: Inlet Right, Outlet Left Hand Side,
MOR23700 Accepts V-8 Ford Or Chrysler Type Spin-On Filters
Flow Direction: Inlet Left, Outlet Right Hand Side,
MOR23710 BILLET OIL FILTER BYPASS PLATE
Accepts V-8 Ford Or Chrysler Type Spin-On Filters
Flow Direction: Inlet Right, Outlet Left Hand Side, MOR23782
MOR23750
Accepts V-8 Chevrolet Type Spin-On Filters Plate is necessary when using a remote oil filter
Flow Direction: Inlet Left, Outlet Right Hand Side, or returning oil from dry sump systems. Plate fits
MOR23760
Accepts V-8 Chevrolet Type Spin-On Filters small block Chevy and accepts -10AN O-ring port
Universal Mount For Large Diameter Filters; 12AN Inlet And fittings. O-rings are captured in the plate for a
MOR23766
12AN Outlet Fittings, One Filter Adapter, Works With Fram HP6 tight seal against the block. Includes mounting
hard ware and O-rings.
BILLET ALUMINUM REMOTE OIL FILTER
ADAPTER FOR GM LS OIL FILTER BLOCK-OFF PLATE
MOR23688 MOR23840
Billet aluminum adapter is ideal when chassis Often used on dry sump oil system installations,
restrictions don’t allow a block mounted filter or plate has a 1/2" NPT port for input pressure line
when a larger external filter is desired. Adapter and fits all small and big block Chevy (except Gen.
includes -10AN inlet and outlet ports and is sold complete V/VI or those with bolt hole at center of pad).
with necessary hardware.
LARGE DIAMETER
OIL BYPASS ELIMINATOR REMOTE OIL FILTER MOUNT
MOR23775 MOR23766
Machined, billet aluminum adapter eliminates the bypass Low profile billet aluminum mount works well in tight
found in OEM small block Chevy filter adapters, preventing areas and has two 3/8"-16 threaded mounting holes,
unfiltered oil from entering the engine. Adapter features -12AN inlet and outlet ports, and a 1/8" NPT for a gauge.
a single inlet and accepts spin-on, stock type oil filters. Includes two adapters to accept a wide range of oil filters
including the Fram HP-6.

OIL FILTER ADAPTERS
Adapters lower filter 1-1/2" and accept accumulators,
external or dry sump pumps, or remote oil coolers. Will RACING OIL FILTERS
fit small block Chevys without modification. Adapters use Rated at 27 microns and provide less pressure drop,
1/2" NPT inlets and outlets. Includes in struc tions, mount- more flow, less oil bypass, and maximum oil filtration.
ing bolts and O-rings. Part No. Description
Part No. Description MOR22459 Chevy Short Style Oil Filter, 4-9/32" Tall
Adapter For MOR22460 Chevy Tall Style Oil Filter, 5-1/4" Tall
MOR23690
Plumbing Accumulators And External Or Dry Sump Pumps Remote Mount,
MOR23692 Adapter For Plumbing Remote Oil Coolers MOR22465 Replaces Fram HP6, 6-1/4" Tall
Ford/Chrysler Tall Style Oil Filter,
MOR22470
5-1/4" Tall
