Page 502 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

NON-GREASABLE EXTREME DROP BENT ALUMINUM UPPER ARM
STEEL MODIFIED TIE ROD TUBES DESIGN LIFT BAR
Extreme drop bent tube Lightweight, aerospace grade aluminum construction
design offers maximum lift bar is not only lightweight,
frame clearance. Tie rod but rigid and durable as well.
tubes are constructed Lift bar includes a special bend for increased pinion clearance and is complete
from .156" wall x 7/8" O.D. round steel, include 5/8"-18 threads and are black with a greasable chrome moly rod end.
powder coat finished. Part No. Description
Part No. Description OPP54-003 Aluminum Upper Arm Design Lift Bar
OPP555-810-BL-NG 10" Bent Left Side Outer Tie Rod OPP54-004 Hardware Kit For OPP54-003
OPP555-815-BL-NG 15" Bent Left Side Outer Tie Rod
QUICK CHANGE
GREASABLE STEEL MODIFIED TIE ROD PINION MOUNTS
ASSEMBLY OPP55-815-SL-M Mounts, offered in 4140 steel or aerospace
grade aluminum construction, are designed to fit
popular Quick Change rears. Back Side Climber
Greasable, 15" long steel modified tie rod assembly is manufactured from style mounts include a slotted arc for adjustment.
.156" x 7/8" O.D. round tube steel and includes 5/8"-18 moly rod ends. Part No. Description OPP61-008-B
OPP61-008-B Steel Back Side Climber Pinion Mount
ONE-PIECE OPP61-011-B Aluminum Back Side Climber Pinion Mount, With Seal Plate
LOWER CONTROL ARMS J-BARS
WITH GREASABLE ROD END
Offered in steel or lightweight,
SYSTEM 7075 aluminum, J-bars incorporate
Standard, one-piece lower control arms are 4140 tool steel adjusters with 1-3/8"
fitted with greasable chrome moly rod of adjustability. All J-bars are fitted with greasable moly rod ends.
ends. Offered for popular dirt late Steel Lift Bar Alum. Lift Bar
model chassis. Description Part No. Part No.
LF Lower RF Lower 17-7/8"-19-1/4", Short Bar With Short Adjuster OPP53-009 OPP53-003
Application Part No. Part No. 19-1/4"-20-5/8", Medium Bar
Rocket (Black), Moly Rod Ends OPP41-002-1-LM OPP42-008-1-RM With Short Adjuster OPP53-011 OPP53-005
Rocket (Blue), Moly Rod Ends OPP41-002-2-LM OPP42-008-2-RM* 21"-22-3/8", Long Bar With Short Adjuster OPP53-013 OPP53-007
* Control arm has dropped shock mount and adjuster.

BREATHER TANKS
POWER Spun aluminum tanks are offered in several configurations.
STEERING RESERVOIRS
Lightweight, 3" diameter spun aluminum tanks are TIG
welded with integral mounting brackets and non-vented
caps. OVC1102
Part No. Description
OVC1001 Round Tank, Attaches To Roll Bar
OVC1102* Square Tank, Weld-On Firewall Mount, -6AN Fitting On RH Side
OVC1202* Square Tank, Weld-on Firewall Mount, -6AN Fitting On LH Side
* Fitting location reference is with the mounting bracket facing the driver.
FUEL OVERFLOW VALVES
Valves are TIG welded spun aluminum.
OVC2001 OVC2004 OVC2010 OVC2340
Part No. Description
OVC5001 1" Flapper Valve Part No. Description
1-1/4" Flapper Valve
Dry Sump/Rear End Breather Tank, Roll Bar Mount, One 1/2" NPT And
OVC5003 With Spring OVC2001 One 3/8" NPT Female Fittings Are 90° From Each Other, One 3/8" NPT
1-1/2" Flapper Valve
OVC5153 Female Fitting At Bottom of Tank, Includes Petcock And Element
With Spring Breather Tank, Roll Bar Mount, 1/2" NPT Female On Side,
OVC2004
Petcock At Bottom, Includes Element
Quick Change Filler With Combo Vent, -10AN To Fill Rear End,
OVC2010
3/8" NPT To Vent Rear End, And 3/8" NPT To Vent Fuel Cell
Breather Tank For Dirt Late Model, Mounts On Deck Metal,
OVC2340
Breathes Out Bottom, 3/4" NPT Vent And Petcock
501
