Page 559 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

QRP66-100
ALUMINUM SUSPENSION TUBES SUSPENSION TUBE RULER
Manufactured in the USA from rigid, 6061 aluminum, QuickCar Suspension Measure nearly any suspension component
Tubes are up to 35% stronger than hex or round units. Suspension tubes fitted with rod ends includ-
include precision machined ends, corrosion resistant black anodized finish and ing suspension tubes, tie
identification on the LH end. Unique design allows easy adjustment by hand rods, etc. Black powder QRP66-105
or with a wrench. Choose from 21/32" O.D. with 5/16"-24 threads, 21/32" coated ruler includes a locking thumb screw and provides precise measure-
O.D. with 3/8"-24 threads, 1-1/8" O.D. with 5/8"-18 threads or 1-1/4" O.D. with ments up to 36". Sold complete with aluminum adapters to measure compo-
3/4"-16 threads. nents with 1/2", 5/8" or 3/4" rod ends. Optional adapters allow measuring
parts with 1/4", 5/16" or 3/8" rod ends.
Part No. Description
21/32" O.D. 21/32" O.D. 1-1/8" O.D. 1-1/4" O.D. QRP66-100 Suspension Tube Ruler
Length 5/16"-24 Threads 3/8"-24 Threads 5/8"-18 Threads 3/4"-16 Threads QRP66-105 Ruler Adapters, Measure Components With 1/4", 5/16" Or 3/8" Rod Ends
6" QRP31-060 – – –
6.5" QRP31-065 – – – QRP66-106 Ruler Adapters, Measure Components With 1/2", 5/8" Or 3/4" Rod Ends
7" QRP31-070 – QRP62-070 QRP75-070
7.5" QRP31-075 – QRP62-075 QRP75-075 SUSPENSION TUBE WRENCH
8" QRP31-080 QRP38-080 QRP62-080 QRP75-080
8.5" QRP31-085 QRP38-085 QRP62-085 QRP75-085 QRP66-6275
9" QRP31-090 QRP38-090 QRP62-090 QRP75-090 Heavy duty steel, double ended
9.5" QRP31-095 QRP38-095 QRP62-095 QRP75-095 wrench allows performing quick adjustments to QuickCar 5/8" or 3/4" O.D.
10" QRP31-100 QRP38-100 QRP62-100 QRP75-100
10.5" QRP31-105 QRP38-105 QRP62-105 QRP75-105 suspension tubing.
11" QRP31-110 QRP38-110 QRP62-110 QRP75-110
11.5" QRP31-115 QRP38-115 QRP62-115 QRP75-115 TORQUE ABSORBERS QRP66-500
12" QRP31-120 QRP38-120 QRP62-120 QRP75-120
12.5" QRP31-125 QRP38-125 QRP62-125 QRP75-125 Track-proven to increase forward
13" QRP31-130 QRP38-130 QRP62-130 QRP75-130 bite out of the turns with
13.5" QRP31-135 QRP38-135 QRP62-135 QRP75-135 sustained traction down
14" QRP31-140 QRP38-140 QRP62-140 QRP75-140 the straight away. Torque Absorbers are
14.5" QRP31-145 QRP38-145 QRP62-145 QRP75-145 IMCA-legal, and are lighter than spring style units. CNC-machined units feature
15" QRP31-150 QRP38-150 QRP62-150 QRP75-150 an internal brass bushing and grease fittings to eliminate any possibility of
15.5" QRP31-155 QRP38-155 QRP62-155 QRP75-155
16" QRP31-160 QRP38-160 QRP62-160 QRP75-160 bind, while the specially-threaded cap allows easy biscuit changes. Offered in
16.5" QRP31-165 QRP38-165 QRP62-165 QRP75-165 three versions; Standard, uses two interior biscuits and is 12-1/2" long; Inter-
17" QRP31-170 QRP38-170 QRP62-170 QRP75-170 mediate, uses three interior biscuits and is 14" long and Long, uses four interior
17.5" QRP31-175 QRP38-175 QRP62-175 QRP75-175 biscuits and is 16" long. Softer or harder durometer biscuits may be purchased
18" QRP31-180 QRP38-180 QRP62-180 QRP75-180 separately for tuning purposes.
18.5" QRP31-185 QRP38-185 QRP62-185 QRP75-185
19" QRP31-190 QRP38-190 QRP62-190 QRP75-190 Part No. Description
19.5" QRP31-195 QRP38-195 QRP62-195 QRP75-195 QRP66-500 Standard Torque Absorber, 12-1/2" Long
20" QRP31-200 QRP38-200 QRP62-200 QRP75-200 QRP66-400 Intermediate Torque Absorber, 13" Long
Long Torque Absorber, 14" Long
QRP66-499
20.5" QRP31-205 – QRP62-205 QRP75-205 Replacement/Accessory Components
21" QRP31-210 – QRP62-210 QRP75-210 QRP66-501 Torque Absorber Biscuit, Extra Soft Blue
21.5" QRP31-215 – QRP62-215 QRP75-215 QRP66-502 Torque Absorber Biscuit, Soft Yellow QRP66-503
22" QRP31-220 – QRP62-220 QRP75-220
Torque Absorber Biscuit, Soft Orange
22.5" QRP31-225 – QRP62-225 QRP75-225 QRP66-503 Torque Absorber Biscuit, Medium Red
QRP66-504
23" QRP31-230 – QRP62-230 QRP75-230
23.5" QRP31-235 – QRP62-235 QRP75-235 QRP66-506 Torque Absorber Biscuit, Hard Black
QRP66-509 Torque Absorber Biscuit, Extra Soft/Soft Green
24" QRP31-240 – QRP62-240 QRP75-240
24.5" QRP31-245 – QRP62-245 – QRP66-512 Torque Absorber Travel Indicator
25" QRP31-250 – – QRP75-250
25.5" QRP31-255 – – – TORQUE ABSORBER COVERS
26" QRP31-260 – – QRP75-260 Durable nylon covers keep
27" – – - QRP75-270 dirt and debris out of
28" – – QRP62-280 QRP75-280
29" – – – QRP75-290 QuickCar torque absorbers,
30" – – – QRP75-300 while also preventing prying
31" – – QRP62-310 QRP75-310 eyes from viewing biscuit colors and combinations. Covers may be easily
32" – – – QRP75-320 installed or removed, and are secured with Velcro.
33" – – - QRP75-330
Part No.
Description
34" – – – QRP75-340 QRP66-520 Cover For 66-500, Standard 12-1/2" Long Torque Absorber
35" – – – QRP75-350
36" – – – QRP75-360 QRP66-530 Cover For 66-499, Long 14" Long Torque Absorber
37" – – – QRP75-370
38" – – – QRP75-380
39" – – QRP62-390 QRP75-390
40" – – QRP62-400 QRP75-400
41" – – – QRP75-410
42" – – – QRP75-420
43" – – – QRP75-430
44" – – – QRP75-440
45.7" – – QRP62-457 –
46.5" – – QRP62-465 –
47.7" – – QRP62-477 –
48" – – QRP62-480 –
48.7" – – QRP62-487 –
49" – – QRP62-490 –
50" – – QRP62-500 –
51" – – QRP62-510 –
72" – – QRP62-600 QRP75-600 CHRIS BRINDLEY JOHN BERGLUND
