Page 554 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

REPLACEMENT GAUGE PANEL COMPONENTS QUICK-LITE WARNING LIGHT KITS
A variety of replacement bulbs, pilot lights, pressure and temperature Warning light kits immediately alert the driver of engine problems. Each kit is
switches are available for use with popular QuickCar gauge panels. sold complete with warning light, sending switch and wiring.
OIL PRESSURE KIT QRP61-711
QRP61-733
Kit includes red warning light, pressure sending
QRP61-691 unit that actuates the warning light if oil pressure
Part No. Description drops below 20 PSI, brass inline tee for oil pres-
QRP61-691 Red LED Bulbs For Standard QuickCar Gauges, Pair sure line, and pre-terminated wiring.
QRP61-692 Blue LED Bulbs For Standard QuickCar Gauges, Pair
QRP61-693 Amber LED Bulbs For Standard QuickCar Gauges, Pair WATER TEMPERATURE KIT
QRP61-694 Green LED Bulbs For Standard QuickCar Gauges, Pair QRP61-712
QRP61-698 White LED Bulbs For Standard QuickCar Gauges, 4-Pack Kit includes blue warning light, temperature
QRP61-699 White LED Bulbs For Standard QuickCar Gauges, Each sending unit that actuates the warning light if water
QRP61-701 Red Warning Light, 3/4" Dia. temperature exceeds 235° F., and pre-terminated wiring.
QRP61-702 Blue Warning Light, 3/4" Dia.
QRP61-704 Yellow Warning Light, 3/4" Dia.
QRP61-706 4-Pc. Warning Light Kit, Includes (1) Red, (1) Blue, (1) Amber And (1) Green OIL TEMPERATURE KIT
QRP61-709 Green Warning Light, 3/4" Dia. QRP61-714
QRP61-730 Fuel Pressure Switch, 1/8" NPT, Activates Warning Light @ 4 PSI Kit includes amber warning light, temperature
QRP61-733 Oil Pressure Switch, 1/8" NPT, Activates Warning Light @ 30 PSI sending unit that actuates the warning light if oil
QRP61-735 Oil Pressure Switch, 1/8" NPT, Activates Warning Light @ 20 PSI
QRP61-740 Water Temperature Switch, 1/2" NPT, Activates Warning Light @ 235°F. temperature exceeds 280° F., and pre-terminated
wiring.
QRP61-748 Water Temperature Switch, 3/8" NPT, Activates Warning Light @ 235°F.
QRP61-750 Oil Temperature Switch, 1/2" NPT, Activates Warning Light @ 280°F. FUEL PRESSURE KIT QRP61-719
Kit includes green warning light, pressure sending
TEMPERATURE AND PRESSURE ADAPTERS unit that actuates the warning light if fuel pressure
Required to connect mechanical water or oil temperature, and pressure drops below 4 PSI, and pre-terminated wiring.
gauges to engine.
WATER PRESSURE KIT
QRP61-713
QRP61-724 QRP611-903
Part No. Description Kit provides instant notice in the event of a blown
QRP61-724 1/8" NPT Female To -4AN Male, Gauge Adapter hose, radiator or head gasket problem. Sold com-
QRP61-725 1/8" NPT Male To -4AN Male, Oil/Fuel Pressure Adapter plete with blue warning light, pressure sending unit
QRP611-900 1/2" NPT Brass Temperature Adapter that actuates the warning light if water pressure
QRP611-901 1/2" NPT Aluminum Temperature Adapter drops below 4 PSI, and pre-terminated wiring.
QRP611-902 3/8" NPT Aluminum Temperature Adapter
3/8" NPT Extended Aluminum Temperature Adapter,
QRP611-903 Required Where Standard Adapter Contacts Manifold
Or Cylinder Head Prior To Tightening
WATER PRESSURE KIT WITH
FUEL PRESSURE ISOLATOR 2-1/16" DIA. GAUGE QRP61-716
QRP61-300 Keep track of spikes or loss of cooling system pressure.
Isolator eliminates the hazards associated with driver’s Kit is similar to the QRP61-713 kit with the addition of a
compartment mounted fuel pressure gauges. Typically mounted 2-1/16" dia., 0-35 PSI water pressure gauge.
to the engine side firewall, isolator is compatible with gasoline, Part No. Description
alcohol or methanol fuels. Manufactured from black Quick-Lite Warning Light Kit
anodized, 6061-T6 billet aluminum, isolator is capable of Replacement Components
Red Warning Light, 3/4" Dia.
QRP61-701
monitoring pressures up to 80 PSI and is sold complete with -4AN adapters and QRP61-702 Blue Warning Light, 3/4" Dia.
mounting hardware. QRP61-704 Yellow Warning Light, 3/4" Dia.
QRP61-709 Green Warning Light, 3/4" Dia.
OIL TEMPERATURE MANIFOLD QRP61-730 Fuel Pressure Switch, 1/8" NPT, 4 PSI
QRP61-755 QRP61-733 Oil Pressure Switch, 1/8" NPT, 30 PSI
Oil Pressure Switch, 1/8" NPT, 20 PSI
Installed in-line to allow monitoring engine oil tempera- QRP61-735 Water Temperature Switch, 1/2" NPT, 235° F.
QRP61-740
ture, manifold is constructed from rigid, billet aluminum. QRP61-748 Water Temperature Switch, 3/8" NPT, 235° F.
Manifold includes -10AN O-ring boss inlet and outlet ports, QRP61-750 Oil Temperature Switch, 1/2" NPT, 280° F.
and a 3/8" female NPT port for an oil temperature probe.
RACE WIRE
FIREWALL JUNCTION MOUNTING BLOCKS Fine stranded, rope-lay copper construction wire offers
Designed to add longevity to any pressure sensor or both high flexibility, superior power flow and insulation
transducer, black anodized aluminum mounting blocks capable of handling extreme temperatures.
allow the sensor to be mounted away from the heat and Part No. Description
vibration created by the engine. The blocks include 1/8" QRP57-2011 14 Gauge Wire, Red, 10' Long
NPT female threads with either two or three holes, providing a clean, remote QRP57-2031 14 Gauge Wire, Black, 10' Long
location to mount all sensors together. QRP57-2361 14 Gauge Wire, White, 10' Long
Part No. Description
QRP63-120 Two Hole Firewall Junction Block
QRP63-130 Three Hole Firewall Junction Block

553
