REAR ENDS AND AXLES

FORD 9" PINION YOKES TAILSHAFT SEAL AND BUSHING
Forged steel or billet aluminum Allstar Pinion Yokes The tailshaft bushing is a regular wear item,
are available for Ford 9". located inside the transmission tailshaft hous-
Part No. Description ing. It should be replaced when replacing the
28-Spline Steel Pinion Yoke, tailshaft seal or when a driveshaft failure has
ALL68380 Use With 1350 (3-5/8") U-Joint occurred. A worn bushing will cause excessive
35-Spline Steel Pinion Yoke, side-to-side movement of the slip yoke and create a vibra-
ALL68382
Use With 1350 (3-5/8") U-Joint tion or leak. Replacement bushing and seal fits GM Power-
28-Spline Aluminum Pinion Yoke, glide, Turbo 350, Saginaw, Muncie, Bert and Brinn transmissions. ALL72152
ALL68384
Use With 1310 (3-1/4") U-Joint Part No. Description
ALL72150 Seal
U-BOLT KITS ALL72152 Seal With Bushing
U-bolt kits for 1310, 1330 and
1350 series U-joints secure drive- STEEL DRIVESHAFTS
shaft to pinion yoke. Sold in pairs Balanced 2-1/2" lightweight D.O.M. steel driveshafts feature heavy duty
with nuts and lock washers. U-joints with grease fittings, and TH-350 or Powerglide slip yoke. Shafts are
U-Joint Stud CTC painted white and available in 30.5" and 31.5" lengths. Uses 1310 (3-1/4")
U-Bolt Series Cap Thread "A" "B" U-joint. Yoke measures 5.50" from U-Joint centerline to end, with 3.50" of slip
Std. ALL69015 1310 1-1/16" 5/16"-24 1.750" 1.400" length.
X-Long ALL69017 1310 1-1/16" 5/16"-24 2.000" 1.400"
Std. ALL69018 1330 1-1/8" 5/16"-24 1.875" 1.575"
Std. ALL69016 1350 1-3/16" 3/8"-24 2.000" 1.625"
Part No. Description
U-JOINTS ALL69020 30.5" Steel Driveshaft
ALL69022
31.5" Steel Driveshaft
Performance U-joints are greasable and fit a U-Bolt Kit For ALL69020 And
variety of driveshaft combinations. ALL69015 ALL69022 (Pair)
ALL69030 1310 U-Joint
1310 Series: 3.218" Wide with 1.062" Caps
1330 Series: 3.622" Wide with 1.062" Caps
1350 Series: 3.622" Wide with 1.187" Caps REMOTE FILL TANKS
(Width = B, Caps = A in drawing) ALL36110
Part No. Description Aluminum fill tank has a -10AN outlet and
U-Joints With Same Cross Width recessed mounting flange to flush-mount on
ALL69030 1310 Series rear deck.
ALL69031 1330 Series ALL36111
ALL69032 1350 Series Designed for filling rear end, tank has a
U-Joints With Different Cross Widths -10AN outlet and recessed mounting flange.
ALL69034 1310 to 1330 Also has 3/8"NPT bung to accept a breather. ALL36110
Description
Part No.
ALL69035 1310 to 1350 Replacement Component
ALL69036 1330 to 1350 Replacement Cap ALL36111
ALL36124 For ALL36110 and ALL36111
SLIP YOKES ALL69042
ALL69043
Slip yokes provide an important link in today’s
driveline and chassis combinations. Yokes are
available in standard length for most street applica- MINI BREATHER TANKS
tions with minimal suspension travel to extra-long for Small capacity, spun aluminum tanks can be used to vent
racing suspensions that have a radical amount of travel. transmission or rear end to prevent lubricant from being forced
27-spline yokes accept 1310 style u-joints and are for out. Tanks are complete with 1/4" NPT bung at bottom and
use in many popular transmissions including TH350, 6-3/4" bracket for mounting to chassis tubing.
TH700R4, Muncie and Saginaw 3 and 4 speeds, Bert and Part No. Description
Brinn non-ball spline. ALL36140 Tank For 1-1/2" Tubing
Part No. Description 4-3/4" ALL36141 Tank For 1-3/4" Tubing
ALL69040 6"
ALL69042 6-3/4" CLAMP-ON BREATHERS
ALL69044 7-1/2" Breathers are easily mounted to either 1-1/2" or 1-3/4"
ALL69046 8" tubing. Breathers are 1" tall and 1-3/8" in diameter. Great
ALL69048 8" (Extra Clearance) for use on transmissions, differentials, etc. Bottom fitting
Hardened is 1/4" NPT. Black anodized finish.
ALL69043 6-3/4" Part No. Description
ALL69045 7-1/2" ALL36106 Breather For 1-1/2" Tubing
ALL69047 8" ALL36107 Breather For 1-3/4" Tubing
ALL36103 Replacement Filter Only
