Page 229 - 2020 Allstar Performance Parts and Equipment Catalog

Valve Spring Compressor ALL96490 Spark Plug
Adjustable C-clamp style Index Shims
compressor will fit most heads Stackable shims index spark plugs at 30°
including Hemi. Spring cup intervals up to 360° properly positioning
will fit stock springs up to ground strap in cylinder head for increased
1.750" diameter and has a power and clearance between spark plug
1.100" “working window” and piston. Shims are intended for use with 14mm flat seat TOOLS & PIT EQUIPMENT
for access to keepers, which may be too large spark plugs only. Package of 24 shims contains 12 silver
for some small diameter spring/retainer combinations. 60°, 12 black 90°, detailed instructions and dial chart.
Compressor has 9/16" hex for use with a wrench, ratchet ALL96505 ..... Shim Kit, Standard O.D. (.800")
or impact. This tool will handle spring pressures in excess ALL96506 ..... Shim Kit, Small O.D. (.720")*
of 1200 lbs. without slipping off.
*Shims are designed for close tolerance spark plug pockets such as those on
ALL-PRO cylinder heads.
Feeler Gauges
Use in engine assembly to check con- Spark Plug Gap Tool ALL96515
necting rod side clearance, piston ring Used to set consistent plug gap.
end gap, spark plug gap and valve lash. Insert plug into holder, then put
Gauges have Metric and SAE sizing designations feeler gauge between ground
etched in each blade. Choose straight or angled sets. strap and electrode. Gently turn
ALL96420 ..... Straight knurled knob until feeler gauge is snug.
ALL96421 ..... Angled
Spark Plug Gap Tool Kit
Valve Lash Wrenches
ALL96516
Allstar Valve Lash Wrenches save Spark plug gap tool quickly and accurately
precious time and eliminate fumbling with two gaps 14mm threaded spark plugs. Thread
separate wrenches. Available for Jesel, T&D and spark plug into tool, place the correct
other poly-lock style rocker assemblies.
size feeler gauge beneath the ground
ALL96400 .... 7/16" Box Wrench, 1/8" Allen Wrench, strap, then tighten knob to set plug gap.
Jesel Assemblies Includes 17 different feeler gauge sizes
ALL96401 ..... 1/2" Box Wrench, 3/16" Allen Wrench,
T&D Assemblies .010" thru .035".
ALL96402..... 9/16" Box Wrench, 3/16" And 7/32" Allen
Wrenches Port And Polish Kit ALL11052
ALL96403..... 5/8" Box Wrench, 3/16" And 7/32" Allen Kit includes an assortment of 60, 80
Wrenches
and 120 grit cartridge rolls for cleaning
and modifying intake and exhaust
Remote Starter Switch Kit ALL76205
ports to match gaskets, remove
Kit includes a low profile, steel casting marks and for smoothing
cased foot pedal with 8' out runners. Two 1/4" mandrels are
cord and assorted wire included with each kit.
ends to work with many
applications. Provides
hands free engine cranking Dykem Layout Fluid ALL12070
when adjusting valves. Apply layout fluid to the work surface
to enhance visibility of scribes during fabrica-
tion. Blue fluid dries in minutes to a uniform,
Remote Starter Button ALL76206 thin film without cracking or chipping. 4 oz.
Kit is very helpful for valve lash main- container has a built-in brush under cap. Not intended for
tenance when the ignition panel can’t use in set up of ring and pinion gear sets.
be reached. Leads are 60" long and
come complete with gator clamps to SB Chevy Engine Covers
connect to starter solenoid.
Covers protect engines during storage
or transport. 1/8" thick polycarbonate
Spark Plug Indexing Tool ALL96510 ALL96532
material is formed to fit most small block
Indexing positions the Chevy applications. Short block cover fastens over cyl-
ground strap of the spark inder head alignment dowels. Manifold cover is
plug properly for best designed to replace manifolds with stock port
piston dome clearance locations and bolt pattern.
and un-shrouds the electrode for a more even burn and ALL96530 ..... Short Block Cover
possible gains of 5-15 horsepower. Works with flat gasket ALL96532 ..... Manifold/Valley Cover ALL96530
or taper seat 14mm spark plugs. Includes instructions.
