Page 248 - 2020 Allstar Performance Parts and Equipment Catalog

TOOLS & PIT EQUIPMENT

Toe Plates Ride Height Set-Up Stick ALL10658
Aluminum plates simplify Stick replaces the coil over shock and spring
setting of toe-in and toe-out. assembly during maintenance. Stick has
Plates fit against outside edges ALL10117 many uses and may be adjusted to
of tires. Using two tape check settings at normal ride height,
measures (sold separately), in race attitude or on the bump
measure the distance front stops to evaluate suspension
and rear, between plates. travel. Adjusts from 15" to
The difference in tape 24", measured at the center
readings is the toe setting. ALL10119 of rod ends.
Deluxe plates have radiused
edges, slots for narrow and wide tape measures and Set-Up Tool ALL10668
are 9" tall x 23" wide to work with vehicles with smaller
wheel openings. Standard plates are 1/2" thick, 11" tall Tool replaces the front coil-over shock assembly to sim-
x 32" wide and work well for vehicles with larger wheels ulate range of front suspension movement for checking
and wheel openings. Set of two plates. bump steer and roll center. Hex head threaded shaft
raises and lowers suspension to simulate racing condi-
ALL10117 ...... Standard tions. Jam nuts can be positioned to limit rebound and
ALL10119 ...... Deluxe
compression. Not designed to support total vehicle
weight, only suspension components.
16' Tape Measure
ALL10675 Set-Up Plates
16' x 3/4" blade has fractional Set-up plates are used for
markings every 1/8" for quick squaring and stringing ALL10660
reference. chassis to ensure accu-
rate chassis set-up by
Caster Kit eliminating wheel and
Measure your front end NEW! tire differences. Plates
caster by attaching an are 1/2" thick and can ALL10662
adapter and level holder to your upper also be used when setting bump steer or
ball joint threads. Additional adapters checking axle tubes for straightness. Sold each.
may be purchased separately for other ALL10660 ..... 5x5, 7" x 28"
use. Digital Level sold separately. ALL10662 ..... Wide 5, 12" x 28"
ALL11162 ...... Kit with holder, BJ adapters
and carry case (No Digital Level) Set-Up Stand
ALL11164 ...... Holder Only for Digital Level Before tire and wheel are removed, measure
ALL11165 ...... Quickchange Pinion Angle Adapters (2) distance from center of hub to the ground.
ALL11166 ...... Late Model Spindle Adapter Remove the tire and wheel, replace with the
ALL10742 ...... 2x2 Digital Level
set-up stand and adjust accordingly.
Adjustments can be made with car at
Caster Plate ALL10752 exact ride height with the wheel and
Not sure if you turned your wheels the tire out of the way. Sold each.
same amount each time when adjusting ALL10664 ..... 5x5
caster settings on your race car? Unless you ALL10666 ..... Wide 5
have expensive turn plates, you’re never
certain, until now. This quick reference gauge positions Upper Ball Joint Wrench
under the upper ball joint nut, with markings facing up,
for easy viewing. Place a mark on the shock body or fabri- ALL11190
cate an indicator to use as a reference point. Wrench is designed to
remove and install common screw-in upper ball
Ground Clearance Indicator joints that are 1.900" wide (ALL56214).
ALL10725
Adjustable Panhard Bar Wrench
Determine how close the frame is to the
ground on the race track. This unique ALL11192
kit features an aluminum bracket that Wrench is designed to
rivets to the frame with an adjustable work with adjustable Panhard bars with 1-3/8"
4" plastic wear rod. adjusters. Shorter than a standard wrench, this wrench is
convenient for making adjustments in tight areas.
Replacement Part
ALL10726 ..... Wear Rods, 4-Pack
