Page 258 - 2020 Allstar Performance Parts and Equipment Catalog

WHEEL & TIRE ACCESSORIES

Wheel Studs Lug Nuts
ALL44115
Larger-than-stock Large diameter, open
studs require end lug nuts are designed
redrilling of stock ALL44110 ALL44117 to fit most racing wheel applications and will not pull
flanges. Check through the wheel. Nuts are available in steel or alu-
sanctioning body ALL44111 ALL44116 minum with SAE or metric threads and feature a 45°
for wheel stud tapered seat.
requirements. ALL44112 ALL44113
Package of 5. Description Pack Of 10 Box Of 100 Box Of 350 Box Of 400
Aluminum Lug Nuts
ALL44114 ALL44119 5/8"-11 (Coarse) ALL44096 ALL44096-100 – –
Double Chamfer
Underhead Thread Knurl Knurl 5/8"-11 (Coarse)
Part No. Size Thread Length Length Length Dia. Double Chamfer § ALL44097 ALL44097-100 – –
ALL44110 1/2"-20 Fine 2.000" 1.625" .650"* .589" Steel Lug Nuts (Heat Treated and Zinc Plated)
ALL44111 1/2"-20 Fine 1.875" 1.125" .500"* .675" 5/8"-11 (Coarse) ALL44098 ALL44098-100 – –
ALL44112 1/2"-20 Fine 2.250" 1.925" .650"* .619" Double Chamfer
ALL44114 5/8"-18 Fine 2.000" 2.000" .560" .685" 5/8"-11 (Coarse) ALL44106 ALL44106-100 – ALL44106-400
ALL44115 5/8"-11 Coarse 2.000" 1.375" .375" .690" 5/8"-18 (Fine) ALL44104 ALL44104-100 – ALL44104-400
ALL44117 † 5/8"-11 Coarse 2.750" 2.125" .375" .690" 1/2"-20 (Fine) ALL44102 ALL44102-100 ALL44102-350 –
ALL44116 ‡ 5/8"-11 Coarse 2.750" 2.125" .725" .690" 7/16"-20 (Fine) ALL44100 ALL44100-100 – ALL44100-400
ALL44113 † 5/8"-11 Coarse 3.750" 3.125" .375" .690" 12mm - 1.25 ALL44103 ALL44103-100 ALL44103-350 –
ALL44119 ‡ 5/8"-11 Coarse 3.750" 3.125" .725" .690" (Metric)
*Length with shoulder. Underhead Length 12mm - 1.5 ALL44101 ALL44101-100 ALL44101-350 –
†Popular 5x5 Hub Wheel Stud Thread Length (Metric) ^
‡Popular Wide 5 Hub Wheel Stud
Knurl Length §Hard coated.
^Most popular metric for GM, Ford and Chrysler.
Hex Pit Sockets
Knurl Diameter
With Extension
Hex style pit
43/64" Wheel Stud Drill Bit ALL11045 sockets with a
43/64" bit is correct for drilling hubs or built-in exten-
axle flanges to accept most 5/8" sion prevent extension and socket from separating during
wheel studs with .690" knurl wheel changes. Bright powder coated finish provides a
diameter. 1/2" shank. durable coating and helps prevent loss in dark pit areas.
3/8" Drive NEW DESIGN!
ALL10234 ..... 5"
Economy Quick Spin ALL10235 ..... 12"
Lug Wrench ALL10108 1/2" Drive
Lug wrench is a 1" ALL10239 ..... 5"
diameter tube with ALL10240 ..... 12"
a shallow 1" socket Super Sockets
welded to one end and
rotating piece of plastic With Extension
pipe attached to Pit sockets are available
the other. The 10" with 5" or 11" extensions
handles are angled and include our Super Socket for fast
with rubber grips and the overall length is 23". wheel changes without jamming lug nuts. Sockets fit 1"
lug nuts and are used with 1/2" drive impact guns.
ALL10242 ..... 5"
ALL10241 ...... 11"
Glueless Lug Nuts
Open end lug nuts attach to the wheel with Aluminum Wheel Adapter
springs for FASTER pit stops! Kits contain 5
glueless lug nuts with springs attached and ALL44128
self-tapping screws for mounting. Adapter bolts to stock 5x4-1/2" or
5x4-3/4" bolt circle hub and adapts to
ALL44107 ..... Complete Kit, 5/8"-18 Thread (Fine)
ALL44108 ..... Complete Kit, 5/8"-11 Thread (Coarse) 5x5" bolt circle pattern wheel. Fitted with
ALL44109 ..... Replacement Spring And Screw, 5-Pack 5/8"-11 coarse thread studs. 1" thick.
