BRAKE Steel Tube Nuts And Sleeves 90° Swivel AN Fitting

Steel tube nuts and sleeves are used when
full 360° for convenient hose connection.
making hard line connections to male AN fit- Black anodized aluminum fitting swivels a
tings. Line requires a 37° flare for proper sealing. ALL50300 1/8"NPT fitting is commonly used in after-
Package of 4. market calipers, gauge panels or anywhere a
ALL50300 ..... -3 Tube Nut swivel connection would be useful.
ALL50310 ..... -3 Tube Sleeve ALL50310 ALL50108 ..... 1/8"NPT to -3AN
ALL50109 ..... 1/8"NPT to -4AN

Aluminum Tube Nuts And Sleeves AN Union Fittings
Black anodized aluminum flare union adapter
Aluminum tube nuts and sleeves are used with ALL50320
corresponding hard lines to connect to male fittings are commonly used to connect two hoses with
AN fittings. Line requires a 37° flare for proper female AN ends.
sealing. Package of 2. ALL50090 .... -3AN to -3AN
ALL50330 ALL50091 ..... -4AN to -4AN
Size (Female) For Tubing O.D. Tube Nut Tube Sleeve
-3 3/16" ALL50320 ALL50330 AN Bulkhead Fittings
-4 1/4" ALL50321 ALL50331 ALL50092
Black anodized aluminum bulkhead ALL50093
adapters are perfect when plumbing
needs to pass through a firewall, inte-
37° Flaring Tool rior panel or a mounting bracket.
ALL11016 ALL50092 ..... Straight -3AN to -3AN
This -AN fitting flare tool is essential ALL50093 ..... Straight -4AN to -4AN ALL50094
when working with 37° flared fit- ALL50094..... 90° -3AN to -3AN ALL50095
tings. Tool for use with soft copper, ALL50095 ..... 90° 4AN to -4AN
aluminum and brass tubing will ALL50096..... Tee (Run) 3AN (3x) ALL50096
ALL50097
precisely flare from -3 to -10 and ALL50097 ..... Tee (Run) -4AN (3x)
3/16" to 5/8". ALL50098..... -3AN Bulkhead Nut
ALL50099 ..... -4AN Bulkhead Nut

Bulkhead Mounting Tab
Quick Disconnect Couplings ALL60093
2-piece couplings allow lines to be One-piece steel
separated without loss of fluid or mounting tab with
requirement of bleeding. ALL50215 7/16" hole can be 1" Square 1"
Commonly used on brake bolted to the chassis Mounting Tab
systems when changing front or rear end to hold shown with
ALL50093 -4AN
or rear axle assembly, hydraulic ALL50212 bulkhead fittings Straight Bulkhead 1-11/16"
wing cylinders, a hydraulic ALL50213 in place. Bracket is Fitting and
ALL50099
clutch system using a hydraulic 5/64" thick. Bulkhead Nut.
throw out bearing or when
servicing a transmission with ALL50209
an internal hydraulic clutch. Retainer Clamp ALL68326
Steel clamp is designed to fit around 3"
ALL50215 ..... Steel Coupling With 1/8"NPT Female Threads
ALL50212 ..... Alum. Coupling With -3AN Male Threads O.D. axle tube and mount other brackets
ALL50213 ..... Alum. Coupling With -4AN Male Threads or keep brackets in place. Lightweight
ALL50209 ..... Premium Coupling Fitting With -3AN Male Threads clamp has 1/4" mounting hardware and a
powder coated black finish.

Half Clamp Brackets
Unique brackets are a must when
clamping completely around tubing
isn’t possible. Bracket clamps just over ALL10464
halfway around tubing and tightens to create a
secure mount for many accessories. 3" bracket can clamp
to rear end axle tubes to neatly secure braided lines.
Brackets have 3/8" mounting holes.
ALL10464 ..... 1-1/4" ALL10468 ...... 1-3/4"
ALL10466 ..... 1-1/2" ALL10470 ...... 3"
