Page 419 - 2018 Racecar Engineering Engine Parts and Accessories Catalog

FLEXPLATES

Chrysler Small And Big Block

Tooth
Part No. Description Count Balance Engine Transmission SFI
JWP93009-C 6-Bolt, With 10.75 T/C Bolt Pattern 130 Internal 318-440 GM Yes
383-440 With 8 Bolt
MEZFP30608 1-Piece Billet Design 10 Pitch With 10.75" T/C Bolt Pattern 130 Internal GM Yes
Flange
383-440 With 8 Bolt
JWP93010 With 10.750" 6-Bolt T/C Bolt Pattern 130 Internal GM Yes
Flange
QTMRM-947 6-Bolt, With GM 4L80E T/C Bolt Pattern 130 Internal 318-440 GM 4L80E Yes
1-Piece Billet Design 10 Pitch Hemi Pro Mod
MEZFPS096 136 Internal — Yes
With 10.75" 6-Bolt T/C Bolt Pattern With 8 Bolt Flange
1-Piece Billet Design 10 Pitch Hemi Pro Mod
MEZFPS027 139 Internal — Yes
With Triple Bolt T/C Bolt Pattern With 8 Bolt Flange
8-Bolt,
MEZFPS020 168 Internal 426 Hemi/ Pro Mod GM Yes
With 6 on 10.75, 3 on 10.75 And 3 On 11.50 T/C Bolt Pattern
1-Piece Billet Design 12 Pitch 426 Hemi With 8 Bolt
MEZFP306168 168 Internal GM Yes
With 10.75" And 11.5" T/C Bolt Pattern Flange
No
BMM10230 With 10.0" And 11.125" T/C Bolt Patterns Ring Internal 318-440 With 6 Bolt A727 Yes
Flange
Gear
No 318-440 With 8 Bolt
BMM10231 With 10.0" T/C Bolt Patterns Ring Internal Flange A727/A904 Yes
Gear
No
1-Piece Billet Design 12 Pitch Hemi Pro Mod
MEZFPS022 Ring Internal — Yes
With Triple Bolt T/C Bolt Pattern With 8 Bolt Flange
Gear
No
MOPP4529751AB With 10.0" T/C Bolt Patterns Ring Internal 318-440 With 6 Bolt A727/A904 Yes
Flange
Gear
No 318-440 With 6 Bolt
TCI145200 With 10.0" T/C Bolt Patterns Ring Internal Flange A727/A904 Yes
Gear
No
TCI145300 With 10.0" T/C Bolt Patterns Ring Internal 426 Hemi With 8 Bolt A727/A904 No
Flange
Gear
No
TCI145600 With 10.0" 5/16" Bolt T/C Bolt Patterns Ring Internal 318-440 With 6 Bolt A727/A904 No
Flange
Gear
Chrysler Cummins Diesel
Tooth
Part No. Description Count Balance Engine Transmission SFI
BDD1041210 Extreme Duty With Stock T/C bolt Pattern 152 Internal 5.9L Diesel 94-07 Chrysler yes
PQX1835910 Extreme Duty With Stock T/C bolt Pattern 152 Internal 5.9L Diesel 88-up Chrysler yes

Ford Small And Big Block
Tooth
Part No. Description Count Balance Engine Transmission SFI
Internal Balance
BMM50246 With 10.5" T/C Bolt Pattern 157 Internal 289, 302, 351W C4 No
JWPN93003 With 10.5" T/C Bolt Pattern 157 Internal 289, 302 Ford Yes
JWPN93003-L With 10.5" T/C Bolt Pattern, Lite-Weight 157 Internal 289, 302 Ford Yes
1-Piece Billet Design With 10.5" 4-Bolt And
MEZFP311 157 Internal 289, 302, 351W Ford/GM Yes
10.75" 3-Bolt T/C Bolt Pattern
Xtreme Duty With 10.5" And 11.375" 4-Bolt And 10.75" And
PQX1830213 157 Internal 289, 302 Ford/GM Yes
11.5" 3-Bolt T/C Bolt Pattern
TCI529615 With 10.5" T/C Bolt Pattern 157 Internal 289-351W, 351-400M C4 yes
ATI915700 * With 11-7/16", 11-1/2" And 10.75" T/C Bolt Patterns 164 Internal 429, 460 C6/E4OD Yes
ATI915722 * With 11-7/16" T/C Bolt Pattern 164 Internal FE 332-428 C6/E4OD Yes
*Must use Aftermarket torque converter,
418 2018 ENGINE BUILDER CATALOG
