Page 421 - 2018 Racecar Engineering Engine Parts and Accessories Catalog

FLEXPLATES

Ford Modular Motor 4.6L/5.4L/5.0L

Tooth
Part No. Description Count Balance Engine Transmission SFI
JWPN93002-468 * For 8-Bolt Crankshafts 164 Internal 4.6L Ford/GM Yes
PQX1828111 With 10.75" And 11.5" T/C Bolt Pattern 164 Internal 4.6l, 5.4L Ford Yes

Oldsmobile

Tooth
Part No. Description Count Balance Engine Transmission SFI
External
ATI915565 With 10.75" And 11.5" T/C Bolt Pattern 166 All V8 GM Yes
25oz
Pontiac
Tooth
Part No. Description Count Balance Engine Transmission SFI
PQX1845503 With 10.75" And 11.5" T/C Bolt Pattern 166 Internal 326-455 GM Yes
PQX1845500 With 10.75" And 11.5" T/C Bolt Pattern 166 External 326-455 GM Yes
SCAFP-455-SFI With 10.75" And 11.5" T/C Bolt Pattern 166 Internal 326-455 GM Yes
TCI399673 With 10.75" And 11.5" T/C Bolt Pattern 166 Internal 326-455 GM Yes

Flexplate Adapter, Shims And Balance Plates

Adapters
Part no. Description
ALL26121 Crankshaft Adapter, GM LS to Early GM Torque Converters ALL26121
HUGHP3795 Crankshaft Adapter, GM LS to Early GM Torque Converters
JWP80002-1 Crankshaft Adapter, BBF to GM Torque Converter
JWP80002-3 Crankshaft Adapter, SBF To GM Torque Converter
JWP80012 Crankshaft Adapter, Chrysler 6-Hole GM Torque Converter
JWP80013 Crankshaft Adapter, Chrysler 8-Hole GM Torque Converter
PQX1800346 Crankshaft Adapter, GM LS to Early GM Torque Converters

Flexplate Spacer Shims QTMRM-940
Part no. Description
QTMRM-935 GM 74-85 (5Pk With 1 Each, .030", .035", .046",.056", .073")
QTMRM-940 GM 86-96 (5Pk With 1 Each, .030", .035", .046",.056", .073")
QTMRM-941 GM LS1 (5Pk With 1 Each, .030", .035", .046",.056", .073")
QTMRM-942 SBM 318/360 (5Pk With 1 Each, .030", .035", .046",.056", .073")
QTMRM-943 SBF 302/351 (5Pk With 1 Each, .030", .035", .046",.056", .073")
TCI399100 GM 74-85 .030"

Flexplate Balance Plates
Part no. Description
ALL26120 1974-85, SBC 400 Balancing Plate
PIOFBP-1 1974-85, SBC 400 Balancing Plate
QTMRM-525 1974-85, SBC 400 Balancing Plate
QTMRM-530 SBC Balancing Plate 86-96
QTMRM-535 SBF Balancing Plate 28 Oz.
QTMRM-536 SBF Balancing Plate 50 Oz.
ALL26120

420 2018 ENGINE BUILDER CATALOG
