Multi-Leaf Springs Leaf Spring Accessories (Cont.)
The same AFCO quality, but with tapered leaves, PTFE rub Leaf Spring Pivot Bushing
blocks between leaves, and front bushings.
AFC20229P
Replaces rubber bushing in Chrys-
ler type springs so front spring eye
can rotate and twist for more consis-
tent handling.

Car Actual Nominal
Part No. Description Weight Arch Rate Leaf Spring Sliders
Chrysler Multi-Leaf Springs Roller bearing design replaces
Chrysler Spring, traditional shackles, preventing
AFC20231 5" Arch 2,300-2,800 lbs. 6-5/8" 142 suspension binding. Designed for use
Chrysler Spring, with 2-1/2" wide leaf springs, slider
AFC20231MHD 2,600-3,000 lbs. 6-5/8" 152
5" Arch includes a 1-1/2" O.D. bushing.
Chrysler Spring, Part No. Description
AFC20231HD 2,800-3,200 lbs. 6-5/8" 166
5" Arch AFC200036 Leaf Spring Slider, Camaro Type
Chrysler Spring, AFC20236S Leaf Spring Slider, Chrysler Type
AFC20231XHD 5" Arch 3,100-3,500 lbs. 6-5/8" 194
Camaro Multi-Leaf Springs
AFC20228LW Camaro Spring 2,300-2,600 lbs. 6-3/8" 153 Lowering Block AFC20244
AFC20228 Camaro Spring 2,500-3,000 lbs. 6-3/8" 176 Aluminum lowering block 1/2" tall.
AFC20228HD Camaro Spring 3,000-3,400 lbs. 6-3/8" 205
AFC20228XHD Camaro Spring 3,000-3,400 lbs. 6-3/8" 238

Reinforced Front Segment Leaf Springs AFC20250
Secondary leaf design features a 10-15% stiffer front segment Lower Spring Plates
that provides increased forward bite, quicker throttle response Steel plate with shock mount.
and improved spring durability. Springs additionally reduce
Part No. Description
wheelbase variations during braking or acceleration to improve AFC20249 LH Spring Plate
overall handling.
AFC20250 RH Spring Plate
Nylon Front Eye Bushing
AFC20229N
Three-piece Chrysler style bushing lets
Car Actual Nominal front eye rotate as spring moves.
Part No. Description Weight Arch Rate
AFC20228RF Camaro Type 2,500-3,000 6-3/8" 176
AFC20228HDRF Camaro Type 3,000-3,400 6-3/8" 205
AFC20231HDRF Chrysler Type 2,800-3,200 6-5/8" 166
Universal Front Spring Mount
Leaf Spring Accessories AFC50200
U-Bolts Mount may be used with Chrysler style
leaf springs.
8 EROWV KDYH RI WKUHDGV DQG ¿ W D[OH WXEHV
7DOO QXWV KDYH PD[LPXP WKUHDG HQJDJHPHQW
Part No. Description
AFC20238 8" U-Bolts, Sold Individually (TQPV (TCOG %JGXGNNG /QFKƂ GF
AFC20238-9 9.5" U-Bolts, Sold Individually AFC40000
Manufactured
AFC20235-2 with the same
grade and
thickness material as the
AFC20235
OEM frame and approved by
IMCA, WISSOTA, USRA, USMTS, DIRTcar, and most other ma-
jor sanctioning bodies. Built-in alignment stops on the locating
Shackles AFC20281 tabs make front stub assembly easy and consistent. Cross mem-
ber has clearance built in the back side for radiator placement
Part No. Description and in the front side for steering components, and is lowered on
AFC20235 Aluminum Shackle Plates, Sold Individually the left upper side for steering shaft clearance. Replacement
AFC20281 Steel Shackle Plates, Sold Individually individual right and left horns and right frame rails are available
Shackle Bolt Kit, for crash repair.
AFC20235-2
Eliminates Rubber Bushing In Chrysler Springs
