Rod End For Lower Control Arms Lower Control Arm Bushings
AFC10820 %XVKLQJV UHGXFH IURQW HQG ZHLJKW E\
Required when installing rod end-style lower control lbs. and include nylon inserts to prevent shock
arms. transfer to the chassis.
Front Rear
Application Part No. Part No.
1978-88 Monte Carlo/
Malibu/Regal/Cutlass AFC20069LW* AFC20076LW*
Modular Ball Joint Ring 1975-77 Monte Carlo/Malibu/Regal AFC20076LW † AFC20077LW †
Ideal when building custom control arms 1973-74 Monte Carlo/Malibu/Regal AFC20075LW AFC20077LW †
IRU PRGL¿HGV EDOO MRLQW ULQJV PD\ EH FRP- 1967-72 Chevelle/ AFC20075LW AFC20076LW
bined with steel suspension tubing to deliver the Malibu/Monte Carlo/Skylark
desired front end adjustments. 1967-72 Camaro/Firebird AFC20075LW AFC20076LW
1968-74 Nova AFC20075LW AFC20076LW
Part No. Description
AFC19060 Standard Ball Joint Ring 1971-96 Caprice/Impala AFC20076LW † AFC20077LW †
AFC19065 10° Angle Ball Joint Ring, LH * Lower A-arm mounts must be drilled 1/2"; use 1/2" mounting bolt.
AFC19066 10° Angle Ball Joint Ring, RH † Signifies bushing with 1/2" I.D. hole.

Standard, Low-Friction, And Extended Ball Joints
$)&2 RIIHUV D FRPSOHWH VHOHFWLRQ RI VWDQGDUG ORZ IULFWLRQ DQG H[WHQGHG EDOO MRLQWV 6WRFN DSSHDULQJ ORZ IULFWLRQ EDOO MRLQWV KDYH
only 2 lbs. of resistance (stock ball joints have as much as 50 lbs.) to reduce rigidity, freeing up the shocks and springs for improved
ZKHHO FRQWURO ([WHQGHG OHQJWK EDOO MRLQWV GUDPDWLFDOO\ LPSURYH ERWK WKH FDPEHU FXUYH DQG UROO FHQWHU ORFDWLRQ UHVXOWLQJ LQ HQKDQFHG
high-speed handling and turning characteristics. Standard ball joints are also available.
Upper Ball Joints Lower Ball Joints
Standard Low Friction Standard Low Friction
Application Part No. Part No. Part No. Part No.
General Applications
1964-72 Chevelle/1967-69 Camaro/1968-74 Nova — AFC20037LF AFC20033 AFC20033LF
1970-81 Camaro/1973-88 Monte Carlo/1977-94 Impala AFC20032 AFC20032LF AFC20039 AFC20039LF
1971-76 Impala/Caprice AFC20032 AFC20032LF AFC20038 —
Racing/Hybrid Applications
AFCO/Harris/Howe/Rayburn/Shaw, Bolt-In AFC20031 AFC20031LF — —
Sm. Screw-In, 1.83" Body At Thread, Upper/Lower, Pinto Taper AFC20034 AFC20034LF AFC20034 AFC20034LF
Troyer, Same Body As AFC20034, Larger Stud — — AFC20035 — AFC20039LF
Most Popular Screw-In, Chrysler, Most Strut Cars — — AFC20036 AFC20036LF
GRT/Howe/Rayburn/Warrior, 1971-76 Impala Spindle, 2.180" — — AFC20038 AFC20038LF
Extended Length Applications
AFCO/Harris/Howe/Rayburn/Shaw, Bolt-In,
1/2" Longer Than AFC20031 — AFC20031-2LF — —
Same As AFC20032LF, But .500" Longer, Bolt-In — AFC20032-2LF — —
Small Chrysler Style, — AFC20034-2LF — AFC20034-2LF
Most Tubular Uppers, 1.83" At Thread, Screw-In, +.500"
3/8" Longer Than AFC20038,
Raises Roll Center On IMCA, 1.980", Press-In — — AFC20038-1 AFC20038-1LF* AFC20032-2LF
1973-88 Malibu/1970-81 Camaro,
Extra Long Pin As AFC20038-1, Press-In — — — AFC20038-4LF
* Spindle may need to be reamed.
