Page 648 - 2019-2020 Racecar Engineering Circle Track Parts and Accessories Catalog

RESRE-BR-PKA14-125
Aluminum Bump Stop Packers
Dual-Rate Spring A must for serious short track racers,
Body Protector Sleeve aluminum bump stop packers are used
to create precision load values in today’s
RESRE-01293-05 bump stop packages. Offered for shock
Sleeve features a slightly smaller I.D. com- absorbers with 14mm (9/16") or 16mm (5/8")
pared to the original Ohlin’s sleeve, allowing the shafts in thicknesses of .032", .063" and .125". Color-coded for
dual-rate slider to move freely over it. HDV\ LGHQWL¿FDWLRQ SDFNHUV DUH VROG HDFK
Part No. Description
RESRE-BR-PKA14-032 14mm (9/16"), .032" Thick, Green
2.25"/2.50" Coil-Over Spring Rubbers
RESRE-BR-PKA14-063 14mm (9/16"), .063" Thick, Silver
Part No. Description RESRE-BR-PKA14-125 14mm (9/16"), .125" Thick, Black
RESS-COSA-43 5 Lb., Red
RESS-COSA-49 10 Lb., White RESRE-BR-PKA16-032 16mm (5/8"), .032" Thick, Gold
RESS-COSA-57 15 Lb., Blue RESRE-BR-PKA16-063 16mm (5/8"), .063" Thick, Red
RESS-COSA-62 20 Lb., Yellow RESRE-BR-PKA16-125 16mm (5/8"), .125" Thick, Blue
RESS-COSA-80 25 Lb., Green
Apollo Bump Stops
Ideal for rough race tracks and applications that experience
low vertical force, Apollo bump stops deliver a very low transi-
Packers tional force before picking up a linear force as the bump stop
mates with the concave surfaces of the divider washers. Pur-
1/16" Thick 1/8" Thick
Description Part No. Part No. chase divider washers separately.
12.7mm, .500" RESRE-BR-PK500-063 RESRE-BR-PK500-125
14mm, .551" RESRE-BR-PK14-063 RESRE-BR-PK14-125
16mm, .625" RESRE-BR-PK16-063 RESRE-BR-PK16-125
Note: Packers are sold each.

Part No. Description
Bump Stop Spacers Bump Stops
Made from billet aluminum. 1.85" O.D. x .625" I.D. x .500" H., 50 Durometer,
RESRE-BR-5153-150
1" Thick 1/2" Thick Black/Soft
Description Part No. Part No.
14mm RESRE-BR-SPCR14-1 RESRE-BR-SPCR14-500 RESRE-BR-5153-160 1.85" O.D. x .625" I.D. x .500" H., 60 Durometer,
16mm RESRE-BR-SPCR16-1 RESRE-BR-SPCR16-500 Purple
RESRE-BR-5153-170 1.85" O.D. x .625" I.D. x .500" H., 70 Durometer,
Green
RESRE-BR-5153-180 1.85" O.D. x .625" I.D. x .500" H., 80 Durometer,
Yellow
Bump Stop System Accessories
RESRE-BR-WASHER-0 RESRE-BR-5153-190 1.85" O.D. x .625" I.D. x .500" H., 90 Durometer,
Part No. Description Blue
RESRE-BR-NT73 Bump Stop Steel Nut, Penske Divider Washers
RESRE-BR-NTBIL Bump Stop Steel Nut, Bilstein RESRE-BR-WSHRA-BTM Bottom
RESRE-BR-SLIDER-14 Bump Stop Slider, Fits 14mm/1/2" Dia. Shafts,
Bilstein/Pro/Koni, etc. RESRE-BR-WSHRA-MID Middle
RESRE-BR-WASHER-0 Bump Stop Divider Washer, Flat RESRE-BR-WSHRA-TOP Top
RESRE-BR-WASHER-5 Bump Stop Divider Washer, 5° Taper
RESRE-BR-WASHER-10 Bump Stop Divider Washer, 10° Taper
Bump Rubber Cups
$YDLODEOH WR ¿W %LOVWHLQ 5( 3HQVNH $)&2 DQG 2KOLQV VKRFN
absorbers.
Part No. Description
RESRE-BRCUP-14/1 Bilstein
RESRE-BRCUP-14/3 RE Suspension
RESRE-BRCUP-16/1 Ohlins, AFCO
RESRE-BRCUP-16/3 3"
RESRE-BRCUP-625/1 Penske RESRE-BRCUP-14/1
RESRE-BRCUP-625/3S Penske, 3"

JIM STERNAMAN JOHNNY B
644 2019-20 CIRCLE TRACK PARTS AND ACCESSORIES
