Aluminum Quick-Change Quick-Change Pull Bar Brackets
Pinion Mount With Climber WEHWM292QC
WEHWM205 Triple-slot pull bar bracket incorporates
Single-side pinion mount features a quick-adjust technology. Slots are located
climber on an arc. 1" in front of axle center, and 1" and 3"
behind axle centerline. Sold in pairs with (2)
adjust pucks, brackets also include 90/10
shock hook-up provisions.
Aluminum Dual-Usage
Quick-Change Pinion Mount Steel Ford 9" Arc Pinion Mount
WEHWM205DU WEHWM230
Mount is manufactured with two
identical sides, allowing it to be For use on popular Ford 9" rears, pin-
UHPRYHG DQG ÀLSSHG LQ WKH HYHQW WKDW ion mount includes a 3" climber slot on
it is damaged due to a crash. Sold an arc that provides quick adjustments,
complete with climber hardware. while helping keep car tracking straight.
Part No. Description
Related Components Steel Quick-Change
WEHWM205CG Climber Gear Pinion Mount WEHWM407
WEHWM205BK Bolt Kit For Aluminum Pinion Mounts Rigid billet steel pinion mount moves
the J-bar slot tight to the center section.
Aluminum Quick-Change Incorporates seal to eliminate the need
Double-Sided Pinion Mount for a seal plate. Includes hardware.
WEHWM205DS
Aluminum double-sided pinion Steel Quick-Change
mount locates climber-style arc slots Pinion Mount WEHWM419
on both the right and left sides of the Identical to the WEHWM219 pinion
pinion. mount, yet machined with an incorporat-
ed seal, eliminating the need for a seal
plate. Includes hardware.
Aluminum Quick-Change Pinion Mount
With Arc WEHWM211 Angled Pinion Mount With Climber
Aluminum pinion mount features a WEHWM197
climber on an arc to maintain track Specially angled pinion mount allows
alignment and run the Panhard bar mounting Panhard bar at an angle off
2-1/2" below the pinion centerline.
of the left side. Sold complete with
climber hardware.
Aluminum Left Side High
Quick-Change Pinion Mount WEHWM181 Adjustable J-Bars
Rigid, billet aluminum pinion Offered in D.O.M. (Drawn
mount mounts to Quick-Change Over Mandrel) steel or light-
rears and includes a top slot that is weight, billet aluminum, J-bars may be adjusted up to 2" without
5" left of centerline, while being 2" disconnecting from chassis.
above at the top and 1" below the Part No. Description
Aluminum Adjustable J-Bar,
centerline at bottom. Quick-adjust WEHWM4016-18 12" Overall Body Length, 5-1/2" Adjuster, 16"-18"
climber design allows easy adjustments. Aluminum Adjustable J-Bar,
WEHWM4018-20
13.5" Overall Body Length, 5-1/2" Adjuster, 18"-20"
Aluminum Adjustable J-Bar,
Steel Quick-Change Pinion Mount WEHWM4019-21 13.5" Overall Body Length, 6-1/2" Adjuster, 19"-21"
WEHWM219 Aluminum Adjustable J-Bar,
Manufactured from high-grade steel WEHWM4020-22 15.5" Overall Body Length, 5-1/2" Adjuster, 20"-22"
for maximum rigidity, single-sided pinion WEHWM4022-24 Aluminum Adjustable J-Bar,
mount includes a climber on an arc that 15.5" Overall Body Length, 7-1/2" Adjuster, 22"-24"
Steel Adjustable J-Bar,
provides quick, easy adjustments, while WEHWM40S18-20 13.5" Overall Body Length, 18"-20"
helping keep rear end tracking straight. Steel Adjustable J-Bar,
WEHWM40S19-21 13.5" Overall Body Length, 19"-21"
Steel Adjustable J-Bar,
WEHWM40S20-22
13.5" Overall Body Length, 20"-22"
Steel Adjustable J-Bar,
WEHWM40S22-24
13.5" Overall Body Length, 22"-24"
