Page 768 - 2019-2020 Racecar Engineering Circle Track Parts and Accessories Catalog

Aluminum Bearing Steel Clamp-On
Suspension Cages Metric Caliper Brackets
Modular aluminum design offers unsur- Fabricated steel caliper brackets, which
passed adjustability and options to dirt late accepts GM Metric calipers, are offered in weld-
models. Four-bar mounts are based on the on and heavy-duty clamp-on versions.
standard 9" center-to-center spacing with Part No. Description
plenty of holes to change indexing. Shock WEHWM200-18L Weld-On, Left Side
plates include 4", 5", 6", and 7" drop options. WEHWM200-18R Weld-On Right Side
Sold complete with necessary hardware and WEHWM200-20HDL Heavy Duty, Clamp-On, Left Side
clamp rings. Shock mounts are sold sepa- WEHWM200-20HDR Heavy Duty, Clamp-On, Right Side
rately.
Part No. Description Metric Caliper Spacer
WEHWM300NDS-L Narrow Double Shear LR Suspension Cage
WEHWM300NDS-R Narrow Double Shear RR Suspension Cage WEHWM270
Spacer is 1/4" thick and allows
using narrow rotors with GM Met-
Quick Adjust Puck WEHWM500QA
ric calipers. Sold each.
Engineered for use on Wehr's
suspension cages, puck eliminates
the need for bolt removal, speeding Metric Front Pinto Caliper Bracket
suspension adjustments. WEHWM303F
Hybrid bracket is designed to mount GM Metric caliper on
Double Shear the front side of a Pinto spindle to allow for shock placement.
Modular 2-Link Bracket Sold each.
WEHWM400-4QA
(QJLQHHUHG IRU PRGL¿ HGV ZLWK D WZR OLQN Steel Brake Floater
rear suspension, double shear modular WEHWM200-16L
quick-adjust bracket is complete with axle Designed for left rear
clamp, shock plate, double shear plate, swiv- applications using a GM Metric
el shock mount, and necessary hardware. FDOLSHU EUDNH À RDWHU IHDWXUHV
a dual-bearing design.
Floater has a double
shear, 1/4" upper plate design, an upper rod with a 1" offset from
Single Shear Modular the center line, and mounting holes that are 5-1/2" and 6-1/2" up
2-Link Bracket WEHWM400-2QA from center.
6LQJOH VKHDU EUDFNHW LV GHVLJQHG VSHFL¿ FDOO\ IRU
two-link cars, and is sold complete with axle clamp, Steel Weld Accessory Clamps
shock plate, swivel shock mount and necessary Lightweight steel clamps, which attach
hardware. directly to 1-1/2" or 1-3/4" round chassis
tubing, are typically used to weld-on
accessories.
Part No. Description
WEHWM43150S 1-1/2" Dia.
WEHWM431750S 1-3/4" Dia.
Pinto Spindle/Front
Metric Caliper Bracket WEHWM303 Accessory Clamp
Modular, bolt-together caliper bracket attaches directly to WEHWM431250
Pinto spindle and accepts GM Metric brake
caliper. Rigid, 3/8" thick bracket can be used Clamp attaches directly to 1-1/4" tube and
on the left or right side, and helps provide may be used to attach a variety of items with-
increased brake stability and improved thread out the need for welding.
retention.

Superlite Clamp-On Caliper Bracket 2" x 3" Rectangle
WEHWM300-24 Weight Mount
Rigid, two-piece billet aluminum caliper WEHWM1323
bracket is engineered to clamp-on to the Billet aluminum bracket provides
axle tube and accepts Wilwood Superlite mounts for ballast on 2" x 3"
caliper.
frame rails. May also be used to
attach other components to frame
rails without welding.
