Clip-In Adapter Fittings 3/16" Nylon Brake Line
Steel adapter fittings provide a bulkhead Compression Fittings
style connection to AN lines that can be
mounted directly to the chassis by using FITTINGS & HOSES
tabs or brackets and retainer clips. Fittings
fit in a 5/8" hole and sold in a pack of 2.
ALL50100 ..... 3/16" Inverted Flare To -3AN
ALL50101 ..... 3/16" Inverted Flare To -4AN ALL48032 ALL48033 ALL48034 ALL48035 ALL48036
ALL50102 ..... 1/8"-27NPT To 3AN ALL50150 ALL48032 ..... 1/8"-27NPT Male To 3/16" Straight
ALL50103 ..... 1/8"-27NPT To 4AN ALL48033 ..... 1/8"-27NPT Male To 3/16" 90 Degree
ALL60029 ..... Bolt-on Tabs 2-Pack ALL48034 ..... 3/16" Union
ALL60030 ..... Weld-on Tabs 4-Pack ALL48035 ..... 3/16" Tee, All Compression
ALL50150 ..... Retainer Clip 4-Pack ALL48036 ..... 3/16" Captured End Caps, 10-Pack
ALL60029 ALL60030
TECH TIP 3/16" Nylon Brake Line Push Lock Fittings

Installation Reference Brake Line Clip
ALL50150
Braided Steel Line
Rigid Brake Line
-3AN Or -4AN To 3/16" ALL48020 ALL48021 ALL48022 ALL48023
Brake Line Adapter
Mounting Tab ALL50100 (-3AN) ALL48020 ..... 1/8"-27NPT Male To 3/16"
ALL60029 Or ALL60030
ALL50101 (-4AN)
ALL48021 ..... 1/8"-27NPT Female To 3/16"
ALL48022 ..... 3/16" Tee, All Push Lock
Inverted Flare Nuts ALL48023 ..... 3/16" Tee, Two Pushlock And One 1/8"-27NPT Male
Flare nuts are used for building custom hard brake
lines, transmission cooler lines, oil lines and fuel Steel Tube Nuts
lines. 3/16" and 1/4" nuts are available to fit most master Tube nuts and sleeves are used when making
cylinder and metering/proportioning valve applications. hard line connections to male AN fittings. Line
Select proper thread size for line used. requires a 37 degree flare for proper sealing. ALL50300
Part No. Size Color Qty. Package of 4.
Flare Nuts For 3/16" Line ALL50300 ..... -3AN Tube Nut
ALL50110 3/8"-24 Zinc Plated 10-Pack ALL50310 ..... -3AN Tube Sleeve ALL50310
ALL50111 3/8"-24 Stainless 10-Pack
ALL50113 7/16"-20 Red 2-Pack Aluminum Tube Nuts And Sleeves
ALL50114 1/2"-20 Green 2-Pack ALL50320
ALL50115 9/16"-18 Olive 2-Pack Aluminum tube nuts and sleeves are used with
Flare Nuts For 1/4" Line corresponding hard lines to connect to male AN
ALL50116 7/16"-20 Zinc Plated 10-Pack fittings. Line requires a 37 degree flare for proper
ALL50117 7/16"-20 Stainless 10-Pack sealing. Package of 2. ALL50330
ALL50118 1/2"-20 Gold 2-Pack Size (Female) For Tubing O.D. Tube Nut Tube Sleeve
ALL50119 9/16"-18 Blue 2-Pack
Flare Nuts For 5/16" Line -3 3/16" ALL50320 ALL50330
-4
ALL50331
1/4"
ALL50321
ALL50140 1/2"-20 Zinc Plated 10-Pack -6 3/8" ALL50322 ALL50332
ALL50141 1/2"-20 Stainless 4-Pack -8 1/2" ALL50323 ALL50333
Flare Nuts For 3/8" Line -10 5/8" ALL50324 ALL50334
ALL50142 5/8"-18 Zinc Plated 10-Pack
ALL50143 5/8"-18 Stainless 4-Pack Quick Disconnect Couplings
Master Cylinder Adapter Fittings 2-piece couplings allow lines to be
separated without loss of fluid ALL50215
ALL41012 or requirement of bleeding.
Fittings adapt master cylinders or combination Commonly used on brake
valves with 1/2"-20 and 9/16"-18 ports to accept systems when changing front ALL50212
3/16" inverted flare brake line with standard or rear axle assembly, hydraulic ALL50213
3/8"-24 fittings. Kit includes one of each fitting. wing cylinders, a hydraulic
clutch system using a hydraulic
throw out bearing or when ALL50209
WARNING: PROP. 65 servicing a transmission with an internal hydraulic clutch.
The products on this page can expose you to lead,
which is known to the State of California to cause ALL50215 ..... Steel Coupling With 1/8"NPT Female Threads
cancer, birth defects or other reproductive harm. For ALL50212 ..... Alum. Coupling With -3AN Male Threads
ALL50213 ..... Alum. Coupling With -4AN Male Threads
more information, go to: www.P65Warnings.ca.gov ALL50209 ..... Premium Coupling Fitting With 3AN Male Threads
