Page 110 - 2018 Allstar Performance Parts and Equipment Catalog

FASTENERS Countersunk Bolt Kit ALL18630 Body Bolt Washers

1-1/4" O.D. aluminum
Kit includes specially designed
washers work with most body
aluminum washers which allow the
socket head fasteners to install flush with
bolts to increase the surface
the surface creating a smooth finished look.
finished look. Washers are 1/8" thick and have a built-in
Many uses include mounting
pocket to accept most body bolts or other washer headed
roofs, side skirts, spoilers area preventing pull-through while providing a smooth
and replacing sharp edged fasteners up to 3/4" in diameter.
fasteners inside cockpit. Kits ALL18633
include washers, bolts and nyloc nuts. Finish 10-Pack 50-Pack
Clear ALL18840 ALL18840-50
Bolt Size Washer O.D. Finish 10-Pack 50-Pack Black ALL18841 ALL18841-50
Countersunk Bolt Kits
#10-24 x 1" 1" Clear ALL18630 ALL18630-50 Threaded Nut Insert
1/4"-20 x 1" 1" Clear ALL18632 ALL18632-50 Insert provides a convenient option to
1/4"-20 x 1" 1" Black ALL18633 ALL18633-50 quickly install and easily remove a 1/4"-20
1/4"-20 x 1" 1-1/4" Clear ALL18634 ALL18634-50 fastener on panels up to 1/8" thick. Insert
1/4"-20 x 1" 1-1/4" Black ALL18635 ALL18635-50
fits into a 3/8" O.D. hole and is held in place
on the backside with a steel serrated locking
nut. Internal threads accept fasteners ideal for
Aluminum Washers ALL18660 ALL18638 mounting dash panels, access panels, body
panels, electrical components or other accessories.
Washer O.D. x I.D. Finish 10-Pack 50-Pack
Countersunk Aluminum Washers Insert Material 2-Pack 10-Pack 50-Pack
1" x #10 Clear ALL18660 ALL18660-50 Steel ALL18547 ALL18547-10 ALL18547-50
1" x 1/4" Clear ALL18662 ALL18662-50 Aluminum ALL18548 ALL18548-10 ALL18548-50
1" x 1/4" Black ALL18663 ALL18663-50
1-1/4" x 1/4" Clear ALL18664 ALL18664-50
1-1/4" x 1/4" Black ALL18665 ALL18665-50 Quick Turn Fastener
Flat Aluminum Backer Washers Insert Plates
1" x #10 Clear ALL18638 – Insert plate directly replaces
1" x 1/4" Clear ALL18639 –
the quick turn spring allowing panels to be bolted
Body Bolt Kit With Clips together or used as a blind nut on a panel with limited
access. Inserts have 1/4"-20 threads and are typically riv-
Kit allows the clip to stay fastened to body eted to the backside of a panel or bracket with 1/8" rivets.
panel or angle bracing when removing ALL18558 ALL19420 ..... 1", 2-Pack
body panels for maintenance or cleaning. ALL19420-10 1", 10-Pack
1/4"-20 thread bolts are 1-1/8" UHL and ALL19422 ..... 1-3/8", 2-Pack
have a built-in captured washer. ALL19422-10 1-3/8", 10-Pack
ALL18656
Bolt Color 10-Pack 50-Pack
Black ALL18558 ALL18558-50 Steel Fender Washers ALL18216
Clear ALL18656* ALL18656-50* Washers have 1/4" I.D., 1" O.D. and are sold
Gold ALL18559 ALL18559-50 ALL18559 100 to a pack.
*NEW!
Replacement Parts
ALL18554 ............ Body Bolt Clips, 10-Pack Spin Lock Nuts
ALL18554-50 ....... Body Bolt Clips, 50-Pack Nuts have a built-in washer with a serrated face
to lock nut tight against panels. 1/4"-20 nuts
Body Bolt Kits are perfect to use as a backer nut with Allstar
Bolts are designed for easy ALL18655 body bolts, nose bolts, and body stud kits.
installation and removal, have ALL18560 Color 10-Pack 50-Pack
1/4"-20 thread and a built-in captured washer. Black ALL18555 ALL18555-50
Nuts have built-in serrations which prevent Gold ALL18556 ALL18556-50
loosening. Body bolts are commonly used to ALL18561 Silver ALL18557 ALL18557-50
fasten body panels and side skirts for easy removal but may
be used anywhere a bolt with a captured washer is needed.
Under-Head Length Color 10-Pack 50-Pack
Black ALL18553 ALL18553-50
3/4"
Clear ALL18654* ALL18654-50*
Black ALL18560 ALL18560-50
1-1/8" Clear ALL18655* ALL18655-50*
Gold ALL18561 ALL18561-50
*NEW! Stewart Friesen
108 www.allstarperformance.com
