Page 109 - 2018 Allstar Performance Parts and Equipment Catalog

Rod End Tapered Spacers
Reducer Bushings Universal spacers have many uses FASTENERS
Steel bushings reduce the rod end pivot including spacing rod ends on linkages
ball I.D. to accept a smaller bolt size. to prevent binding or just to provide
clearance. Spacers provide a finished
O.D. To I.D. 2-Pack 10-Pack look when fitting body panels or spacing com-
1/2" To 3/8" ALL18565 ALL18565-10 ponents away from floors and firewalls. Package of 2.
5/8" To 1/2" ALL18566 ALL18566-10
3/4" To 1/2" ALL18567 ALL18567-10 I.D. Small O.D. Large O.D. Length Steel Aluminum
3/4" To 5/8" ALL18568 ALL18568-10 1/4" – ALL18700
1/4" .345 .500
1/2" – ALL18702
High Misalignment 5/16" .475 .625 1/4" – – ALL18706
ALL18708
1/2"
Reducer Spacers 1/4" – ALL18712
Dual purpose spacers 3/8" .525 .680 1/2" – – ALL18714
ALL18716
1"
reduce fastener size 1/4" ALL18570 ALL18590
mounting hole and allow the rod end to 3/8" ALL18571 –
rotate more than 30 degrees in each direc- 1/2" .740 .995 1/2" ALL18572 ALL18592
tion which is 25% more than most standard 3/4" ALL18574 ALL18594
1"
ALL18596
spacers. Stainless steel spacers resist rust and 1-1/2" ALL18576 ALL18595
ALL18578
corrosion. Package of 2. 1/4" ALL18580 ALL18597
1/2" ALL18582 ALL18598
Rod End O.D. Length Overall 5/8" .825 .995 3/4" ALL18584 ALL18599
Size I.D. “A” “B” Width “C” Part No. 1" ALL18586 –
5/8" 1/2" .750" .465" 1.68" ALL18785 1-1/2" ALL18585 –
3/4" 1/2" .890" .475" 1.825" ALL18786 1/2" ALL18587 –
3/4" 5/8" .890" .475" 1.825" ALL18787 3/4" .950 1.125 3/4" ALL18588 –
1" ALL18589 –
5/8" Rod End Reducer Spacers
Reducer spacers fit into 5/8" Shock Spacers
rod ends, reducing the hole Steel spacers have a 1/2" I.D. and
size for 1/2" hardware while 3/4" O.D. and can be used in a
also spacing the rod end variety of other locations.
away from chassis brackets. ALL18615 ALL18612 Length 2-Pack 10-Pack
Standard spacers are 3/4" O.D. and flanged spacers have 1/4" ALL64280 ALL64280-10
1" O.D. flanges to help support rod end. Size referenced 1/2" ALL64282 ALL64282-10
indicates the amount of space between rod end pivot ball 5/8" ALL64283 ALL64283-10
and chassis bracket. Package of 2. 3/4" ALL64284 ALL64284-10
Standard Spacers
ALL18615 ...... Aluminum, 1/2" Flush Mount Bolts
ALL18617 ...... Aluminum, 1" 1/4"-20 flush mount bolts have a 1"
Flanged Spacers O.D. beveled head to provide a smooth
ALL18611 ...... Aluminum, 1/4" finished appearance and are slotted for
ALL18613 ...... Aluminum, 1/2" installation with a standard screwdriver.
ALL18610 ..... Steel, 1/4" Excellent choice when securing body
ALL18612 ...... Steel, 1/2" panels, roof panels, nose supports,
spoiler sides and many other uses. Size
Aluminum Flat Spacers noted is under head length. Package of 10.
Flat spacers are great for shimming and Length Steel Aluminum Black Aluminum
adding additional clearance to brackets for 3/4" ALL18640 ALL18641 ALL18642
brake calipers, power steering, alternators, dry sump 1" ALL18645 ALL18646 ALL18647
pumps or just about anything to help with alignment 1-1/4" ALL18650 ALL18651 ALL18652
issues. Package of 2.
Nose Bolt Kit
Thickness 3/8" I.D. (11/16" O.D.) 1/2" I.D. (1" O.D.)
1/8" ALL18740 ALL18760 Kit provides a nice, smooth finished look
1/4" ALL18742 ALL18762 on the top edge of nose panels when
3/8" ALL18744 ALL18764 installing lower nose supports. Kit
1/2" ALL18746 ALL18766 includes 10 bolts, flat washers and
flanged nuts.
ALL18562 ..... 2" Long Kit
ALL18563 ..... 2-1/2" Long Kit

www.allstarperformance.com 107
