Page 160 - 2018 Allstar Performance Parts and Equipment Catalog

SPRINT CAR COMPONENTS

Half Box Steering Gear Mount Sprint Aluminum ALL55000
Mount is designed for quick instal- Torsion Arms
lation and removal of the Manufactured from 2024 ALL55004
steering gear box. Three Aluminum. Arms are excep- ALL55002
hex cut slots eliminate tionally strong and will not
the need to remove snap ring and flex. Available with black
end cap and allow the steering box to slide easily into or clear anodized finish.
place. CNC-machined from 3/8" thick 2024 aluminum for Hardware included. ALL55005
strength yet only weighs .60 Lbs.
ALL52112 ...... Clear ALL55010
ALL52113 ...... Black ALL55036

ALL55012
Power Steering Lines
ALL55034
Description Black Finish Clear Finish
Front
ALL48260
Assembled lines for power steering have -6AN Left ALL55000 ALL55001
ends and are compatible with high pressure pumps found Left S-Bend* ALL55002 ALL55003
in today’s sprint cars where standard hose and fittings Right Clear ALL55004 ALL55006
cannot be used. Lines are lightweight yet strong, weighing Right Angle Broach ALL55005 ALL55007
Rear
less than a standard high pressure hose assembly. Left ALL55010 ALL55011
Plumbing is perfect for connection of KSE steering gear to Right ALL55012 ALL55013
pump. 13-1/2" long. XP Left ALL55034 ALL55035
ALL48260 ..... Line With Steel Ends And Protective Wrap XP Right ALL55036 ALL55037
ALL48261 ..... Line With Aluminum Ends *S-Bend Provides Added LF Tire Clearance.

Power Steering Supply Line HD Billet Rear Torsion Arms
ALL48262
Gen2 supply line has a 90°
-10AN and a straight -10AN
aluminum fitting for a precise
fit to the KSE Gen2 steering
gear. New style hose is very flexible yet will not collapse
under suction. Total overall length including fittings 9".
Heavy duty, billet aluminum arms have a high resistance
Molded Steering Wheel Pad to twisting ensuring a straight rear end while eliminating
ALL52322 inconsistent spring rates. LR arms are appx. 3.05 lbs. RR
Molded pad fits flat or dished 3-spoke arms are appx. 2.90 lbs. Pinch bolt included.
steering wheels. Velcro straps are Black Clear
permanently secured to pad for quick Left ALL55014 ALL55015
installation. Right ALL55016 ALL55017

Steering Wheel Pad Titanium Pinch Bolt Kit For Torsion Arms
ALL52320 And Pitman Arms ALL17032
Black vinyl covered pad fastens to most three Kit includes five bolts to replace standard
spoke racing steering wheels with three 3/8"-24 x 1-7/8" hardware found in most
hook/loop straps. 5-3/4" diameter foam pad torsion and pitman arms. Bolt kit weighs
is 2" thick. less than 90 grams.

Kody Swanson Shane Stewart Photo: Phil Jordison
