Chief Architect X10 Reference Manual

1 The full pathname of the .pdf file 3 Specify how much of the .pdf file you
displays here. If the pathname is not wish to Import. When multiple pages
that of a valid .pdf file, this text will display are imported, a separate PDF box is created
in red. for each one.
• Click the Browse button to choose a new • Select Current Page to import only the
.pdf file or to relink to a missing file. page specified above and shown in the
• Specify the Page of the .pdf file that dis- preview to the right.
plays in the preview on the right. Type a • Select Pages, then specify the starting
page number in the text field or use the page in the From field and the ending
arrow buttons to browse the pages page in the To field.
sequentially. • Select All to import the entire .pdf file.
2 A preview of the page selected above
displays here.

PDF Box Specification Dialog

Select an imported PDF box and click
the Open Object edit button to open
the PDF Box Specification dialog.

1154
