Layer Set Defaults Dialog



                                                                       •  C  h  e  c  k     Replace Identically Named Lay-
                                                                          ers to replace any layers present in the
                                                                          destination file if they have identical
                                                                          names to layers being imported. When
                                                                          unchecked, layers in the destination file
                                                                          may be replaced by imported layers with
                                                                          different names. Generally, this box
                                                                          should be checked unless you wish to
                                                                          reset existing layer names in the destina-
                                                                          tion file.
                                                                       •  When the desired layer sets are selected,
                                                                          click OK to close the dialog and import
                                                                          them.
                                                                       As layers sets are imported, the program
                                                                       checks the destination file for any layers with
                               •  Check the box beside the name of each   the same name as those being imported. If a
                                  layer set that you would like to import.
                                                                       layer in the destination file has an identical
                               •  Click the Select All button to select all   name to a layer being imported, it will be
                                  sets in the list.                    replaced by the imported layer.
                               •  Click the Clear All button to deselect all
                                  sets in the list.



                          Layer Set Defaults Dialog

                                    The Layer Set Defaults dialog is used   then select “Layer Sets” from the list and
                                    to specify the initial layer sets for   click the Edit button. See “Default Settings”
                               different view types. Select Edit> Default   on page 86.
                               Settings to open the Default Settings dialog,





















                                                                                                       199
