P. 202

Chief Architect X10 Reference Manual



                           into that group. The default group for the   You can specify the default Drawing Group
                           selected object is noted as such.    for most types of objects in their defaults
                        •  When multiple objects in different groups   dialogs. See “Default Settings” on page 86.
                           are selected, “No Choice” will initially   You can also assign a selected object to a
                           display. You can select “Default: Multi-  particular Drawing Group in its
                           ple Values” to return each object to its   specification dialog. See “Line Style Panel”
                           respective default group.            on page 301 and “Layer Panel” on page 195.



                   Display Toggles

                        There are a number of toggles and tools that   •  I  f     Color    is toggled off in any line
                        can be used to affect the appearance of the   based view, including floor plan view,
                        on-screen display.
                                                                   Vector Views, Line Drawing views, CAD
                                                                   Details, and layout, the view will be dis-
                                   Print Preview                   played either in black and white or gray-
                             Print Preview and its related display   scale, depending on the Color Off Is
                             toggles allow you to get a sense of   setting in the Preferences dialog. See
                        what the current view will look like when it   “Appearance Panel” on page 105.
                        is printed. See “Print Preview” on page 1327.
                                                                To display views in gray scale
                                 Refresh Display
                                                                1.  Select View> Color    to toggle color
                             Refresh Display redraws the current   off.
                             window to clean up extra lines, show
                        missing items, and correct random on-screen   2.  Select Edit> Preferences    to open
                        effects caused by changes to a model. Select   the Preferences dialog.
                        View> Refresh Display or press the F5 key   3.  On the APPEARANCE panel, select Gray-
                        to refresh the on-screen display.          scale as the Color Off Is setting. See
                                                                   “Appearance Panel” on page 105.
                                   Color On/Off
                                                                To display views in black and white
                             The display of color on-screen can be
                             toggled on and off in any view by
                        selecting View> Color or by clicking the   1.  Select View> Color    to toggle color
                        toggle button.                             off.
                        •  I  f     Color    is toggled off in any 3D   2.  Select Edit> Preferences    to open
                           view other than a Vector View or a Line   the Preferences dialog.
                           Drawing view, the view will be displayed   3.  On the APPEARANCE panel, select Black
                           in grayscale.                           and White as the Color Off Is setting.




                   202
