Chief Architect X10 Reference Manual

• Framing - Lists ceiling framing and any
• Orthographic a n d Perspective Floor
other materials specified in all Ceiling
Overviews , which show the Current Structure Definitions in the current plan.
Floor, not including its ceiling, plus any • Wall Board - Lists ceiling finish materi-
floors beneath it.
als specified in all Ceiling Finish Defini-
• Wall Elevation views, which show a tions in the current plan.
wall on a single floor, in a single room. • Insulation - Floor insulation is calculated
See “3D View Tools” on page 1047. for all rooms that have a floor, and ceiling
insulation is calculated for all rooms that
In the Materials List have a ceiling - regardless of the Floor or
Ceiling Structure Definition. When a ceil-
The materials that make up floor and ceiling ing is not present, insulation is calculated
platform assemblies are listed under different for the roof. See “Structure Panel” on
Categories in the Materials List: page 436.
• Subfloor - Lists floor framing and struc- • Foundation - Lists the concrete and mesh
tural subflooring materials specified in all for all Floor Structure Definitions in the
Floor Structure Definitions in the current current plan with a layer of concrete
plan. See “Floor and Ceiling Platform material. See “Material Types” on page
Definitions” on page 428. 1024.
• Flooring - Lists flooring and subflooring See “Materials Lists” on page 1263.
materials specified in all Floor Finish
Definitions in the current plan.

Exchanging Floors
Select Build> Floor> Exchange The floor that was moved becomes the
With Floor Above or Exchange current floor at its new location. You can
With Floor Below to swap the current floor easily move a floor up or down several floors
with the floor above or below. by using either one of these buttons
repeatedly.

Copying Floors

• Make a copy of an existing floor to be
The Edit Area tools can be used to make
copies of entire floors in a plan. See “Edit pasted onto a new floor.
Area Tools” on page 271. You can use these • Make a copy of all existing floors in a
tools to: plan to be pasted into a different plan.

718
