Chief Architect X10 Reference Manual

4 Display Options allow you to control and fill styles. When this is unchecked,
how the lines and fill patterns of objects objects display according to their layer
in the Reference Floor appear. settings in the Reference Floor Layer Set.
• Select Draw Reference Floor First to • Use XOR Drawing changes the color of
draw the Reference Floor before drawing lines in the Reference Floor that are
the objects on the current floor. The lines drawn on top of other lines. Lines with
and fill patterns of objects in the Refer- identical properties do not display. When
ence Floor display behind the current unchecked, the Reference Floor color
floor. does not change, and identical lines are
• Select Draw Reference Floor Last to not suppressed.
draw the Reference Floor after the objects
on the current floor are drawn. The lines Swap Floor/Reference
and fill patterns of objects in the Refer- If one floor is defined as the current
ence Floor display in front of the current floor and another floor is defined as
floor, and may cover objects on the cur- the reference floor, select Tools> Reference
rent floor partially or completely. Floors> Swap Floor/Reference to switch
• Use Object Settings displays the line and the status of the two floors.
fill styles of objects in the Reference
Floor that aren’t using their default line

724
