INSTALLATION & STARTUP
Chapter 16 Dryers
Side Kick® Floor Mounted
Nozzle Housings
4) Once the mount brackets and motors are set, set the housing angle to 20° from straight as shown in the image below.
When setting the final angle, rotate the impeller before tightening the bolts this will ensure that the cone will not rub on the
impeller when the dryer turns on and eliminate the need to readjust after this step.
20° 20°
Utility Connections
The Saber® machine is available only in a low voltage scenario; however, if high voltage is a site requirement then
the On-Board Dryer as well as the Side Kicks® can be wired as high voltage. Refer to the electrical schematics to
properly run and wire the dryers.
