2018 National Home Improvement Estimator, All Rights Reserved Page 159

Half-circle fixed vinyl windows. Installed in an opening that’s already framed to the correct size. Dual
glazed, white frame. Low-E insulating glass. Stock units for new construction. Dimensions are width by
height.
20" x 10" B1@2.75 Ea 537.32 100.20 637.52
30" x 16" B1@2.75 Ea 537.32 100.20 637.52
40" x 20" B1@2.75 Ea 709.02 100.20 809.22
50" x 26" B1@2.75 Ea 847.39 100.20 947.59
60" x 30" B1@2.75 Ea 961.52 100.20 1,061.72
80" x 40" B1@2.75 Ea 1,403.90 100.20 1,504.10

Vinyl jalousie windows. Installed in an opening that’s already framed to the correct size. Positive
locking handle for security. By opening size, width by height.
24" x 35-1/2", clear BC@1.00 Ea 279.77 40.26 320.03
24" x 35-1/2", obscure glass BC@1.00 Ea 319.16 40.26 359.42
30" x 35-1/2", clear BC@1.00 Ea 296.94 40.26 337.20
30" x 35-1/2", obscure glass BC@1.00 Ea 339.36 40.26 379.62
36" x 35-1/2", clear BC@1.00 Ea 308.05 40.26 348.31
36" x 35-1/2", obscure glass BC@1.00 Ea 363.60 40.26 403.86

Hopper vinyl windows. White. Installed in an opening that’s already framed to the correct size. Does
not include finish or trim work. Low-E insulating glass. Argon filled. Frame depth 3-5/16". With screen.
Stock units for new construction. By opening size, width by height.
32" x 15" B1@.500 Ea 66.26 18.23 84.49
32" x 17" B1@.500 Ea 66.26 18.23 84.49
32" x 19" B1@.500 Ea 66.26 18.23 84.49
32" x 23" B1@.500 Ea 78.58 18.23 96.81

Vinyl-Clad Wood Windows

Vinyl-clad double-hung Low-E insulated glass wood windows. Prefinished pine interior. White
vinyl exterior. Tilt sash. For new construction. By nominal (opening) size, width by height. Actual width
is 1-5/8" more. Actual height is 3-1/4" more. Includes factory-applied extension jamb for 4-9/16" wall.
Add the cost of screens and colonial grilles.
24" x 36" B1@.500 Ea 191.90 18.23 210.13
28" x 48" B1@.500 Ea 235.33 18.23 253.56
28" x 36" B1@.500 Ea 200.99 18.23 219.22
28" x 42" B1@.500 Ea 218.16 18.23 236.39
32" x 48" B1@.750 Ea 247.45 27.34 274.79
32" x 57" B1@.750 Ea 274.72 27.34 302.06
32" x 36" B1@.750 Ea 212.10 27.34 239.44
36" x 42" B1@.750 Ea 242.40 27.34 269.74
36" x 48" B1@.750 Ea 259.57 27.34 286.91
36" x 54" B1@.750 Ea 277.75 27.34 305.09
36" x 57" B1@.750 Ea 175.74 27.34 203.08
Deduct for non Low-E glazing, per SF of opening --@.000 SF -1.72 -- -1.72
