Page 314 - 2018 National Home Improvement

2018 National Home Improvement Estimator, All Rights Reserved Page 255

Prelude® suspended ceiling system cross tee, Armstrong. Intermediate-duty performance. Meets
all building codes for non-residential construction. Hot-dipped galvanized, rust-resistant steel.
Double-web construction. Requires only 2-1/2" clearance.
2', stab-in, white BC@.033 Ea 1.45 1.33 2.78
4', stab-in, white BC@.033 Ea 2.49 1.33 3.82

Prelude® fire guard suspended ceiling system cross tee, Armstrong. Fire rated intermediate-duty
performance. Meets all building codes for non-residential construction. Hot-dipped galvanized,
rust-resistant steel. Double-web construction. Requires only 2-1/2" clearance.
2', stab-in BC@.033 Ea 2.09 1.33 3.42
4', stab-in, white BC@.033 Ea 2.53 1.33 3.85

Prelude® suspended ceiling system main beam, Armstrong. Intermediate-duty performance.
Hot-dipped galvanized, rust-resistant steel. Double-web construction. PeakForm™ end. 12.6 pound per
foot carrying capacity.
12', white BC@.167 Ea 6.63 6.72 13.35
12', fire guard, white BC@.167 Ea 7.11 6.72 13.83

Prelude® suspended ceiling system wall molding, Armstrong. Fire rated performance. Hemmed
edges. Hot-dipped galvanized, rust-resistant steel, 12' x 7/8" x 7/8", 0.018" thick. Meets all building
codes for non-residential construction.
12', white BC@.167 Ea 4.81 6.72 11.53

CeilingMAX™ zero-clearance ceiling tile grid system. Surface mounting for covering old plaster,
drywall or paste-up ceilings. No wires to hang or leveling required. Top hanger fastens directly to joists
or existing ceiling. Use any 2' x 2' or 4' x 4' acoustic ceiling tile. Eliminates demolition and
re-installation. Runner snaps into top hanger to lock entire grid system and ceiling panels. Cross tee is
installed perpendicular to top hanger to support ceiling panels. Wall bracket is installed around
perimeter of room. Grid snaps out to access plenum above the grid. White vinyl.
2' cross tee BC@.033 Ea 1.52 1.33 2.84
8' runner insert BC@.333 Ea 5.94 13.41 19.35
8' top hanger BC@.333 Ea 7.06 13.41 20.47
8' wall bracket BC@.111 Ea 3.78 4.47 8.25

Drill tip suspension lag screws.
Package of 100 --@.000 Ea 40.91 -- 40.91

White rivets.
Package of 100 --@.000 Ea 4.10 -- 4.10

Ceiling wire hanging kit. Contains nine 12 gauge support wires and nine J-hook nails. Suspends 256
square feet with main tees supported on 4' centers.
Ceiling wire kit BC@1.67 Ea 5.37 67.23 72.60

Suspended ceiling installation kit, Armstrong. Kit includes everything needed to install 64 square
feet of suspended ceiling grid. White.
2' x 2' grid BC@1.25 Ea 47.47 50.33 97.80
2' x 4' grid BC@1.25 Ea 35.25 50.33 85.58

Random textured suspended ceiling panel, Armstrong. Square lay-in panel. Recommended for use
with Prelude 15/16" exposed-tee grid. Class A fire-resistance. Reduces sound by 55%. 5-year limited
warranty.
2' x 2' x 5/8" thick BC@.027 Ea 2.63 1.09 3.71
2' x 4' x 5/8" thick BC@.056 Ea 6.27 2.26 8.53
