Urinal. One-gallon flush. Labor includes setting and connection only. Add the cost of a flush valve,
hanger and piping.
3/4" top spud, white P1@1.50 Ea 262.60 59.51 322.11

Urinal. Vitreous china. Flushing rim. Elongated 14" rim from finished wall. Washout flush action.
Includes two wall hangers and outlet connection. Labor includes setting and connection only. Add the
cost of a flush valve, hanger and piping.
3/4" top spud P1@1.50 Ea 409.05 59.51 468.56

Toilet Installation and Repair

Low-Boy toilet supply hook-up kit. For iron pipe or copper tube stub-outs. Kit includes 1-1/2" female
pipe thread by 3/8" OD tube compression by 1/2" male pipe thread union adapter, and Teflon® tape.
Includes 9" braided Speedi-Plumb water supply connector.
Kit P1@.250 Ea 25.25 9.92 35.17

Angle valve.
1/2" with 3/8" x 12" supply tube kit P1@.250 Ea 11.11 9.92 21.03

Toilet Supply Line. Braided stainless steel.
3/8" x 7/8" x 12" supply line P1@.150 Ea 4.95 5.95 10.90

Decorative flexible supply stop. 1/2" iron pipe size by 3/8" outside diameter.
Angle valve, polished brass P1@.250 Ea 12.22 9.92 22.14

No-Seep wax toilet bowl gasket. Wax gasket with polyethylene flange fits 3" and 4" lines, closet
bowls only. Includes 1/4" x 2-1/4" brass bolt kit with stainless washers and brass nuts.
With brass bolt kit P1@.100 Ea 6.77 3.97 10.73

Cast iron water closet flange. Use on heavyweight plastic or soil pipe. Complete with body, brass
ring, bolts and gasket.
4" diameter, compression P1@.250 Ea 16.26 9.92 26.18

Toilet base plate cover. For toilet replacement. Conceals ring around smaller base of new toilet.
Plastic. Plates can be stacked to raise toilet. 11" wide.
Round nose, 22-1/2" long P1@.080 Ea 17.17 3.17 20.34
Square nose, 18-3/4" long P1@.080 Ea 15.35 3.17 18.53

Leak Sentry™ anti-siphon toilet fill valve, Fluidmaster. Prevents automatic refill of a leaky tank. At
most, only one tank of water can escape a toilet. Toilet always remains operational. Bowl refill
adjustment prevents wasteful overfilling. Fits most toilets, including 1.6 gallon-per-flush models.
Corrosion-resistant plastic and stainless steel.
1.6 gallon flush P1@.300 Ea 12.73 11.90 24.63

Complete toilet tank repair kit, Fluidmaster. Includes flush valve with Adjust-Flush™ flapper,
anti-siphon fill valve, Sure-Fit® tank lever, 3 bolts and gasket. Flapper dial regulates volume. Valve
height adjusts 9" to 14". Lever trims and bends to fit. Universal gasket.
Kit P1@.850 Ea -- 33.72 33.72

One-piece toilet repair kit, Fluidmaster. Replaces many one-piece toilet assemblies. Fewer parts.
Ideal for wet or dry inlet tubes.
Kit P1@.850 Ea 52.82 33.72 86.54

Tank-to-bowl bolt kit, Fluidmaster. Two 5/16" x 3" brass bolts with washers and wing nuts.
Kit P1@.275 Ea 4.92 10.91 15.83
