JACK PLATES/TRIM UNITS
HI-JACKERTM JACKING PLATE • 3/8" Aluminum
– Two Piece Design • Natural Aluminum Finish • Dual Stainless Steel
Adjustment Rods • Maximum 150 HP V4 & V6 Outboards • 6" Setback – 4" Vertical Lift
ORDER NO. 205-30001
Mfr. No. JP-1A-DP
MINI-JACKERTM
• "Clamp Style" Small Outboard Jack Plate • Cast Aluminum Bracket • Marine Grade Transom Block • 4" Setback – 3" Vertical •MaxWt–150lbs MaxHP–35
PT-35 ELECTRIC HYDRAULIC TILT & TRIM Rated for 35hp & smaller motors! Offers power tilt & trim, better boat handling, more speed, lower fuel consumption and no more back strain!! •5-1/2" set back to enhance boat stability and performance •1/4" 6061 T6 extruded aluminum construction with S.S. fasteners •For clamp-on or bolt-on motors without the need for an adapter •Trim & tilt: 84˚
Note: The inside dimension of the motor mounting area of the PT-35 is 11". Before ordering, please make sure that the maximum width of the clamp mounting feet and/or mounting bolts of the motor that must fit into this area does not exceed this 11" limit. Refer to the transom
view drawings on mfr. website.
•Mounting bolts are not included with the PT-35 •Electric hydraulic actuator rating: 7853 lbs. of thrust •Weight: 24 lbs.
ORDER NO. 205-52100
Mfr. No. 52100
HYDRAULIC JACK PLATE GAUGE KIT
PRO HI-JACKERTM JACKING PLATES • Locking Bars Allow One Wrench Adjust • Mirror Finish • Maximum 175 HP Outboards • 4" Vertical Adjustment • High Strength Aluminum – 3/8" Thick • One-Piece Design – Top Adjust • 6" Set back
ORDER NO. 205-00600
Mfr. No. JP-6PW-DP
ORDER NO. 205-50001
Mfr. No. MJ-1-DP
PT-130 ELECTRIC HYDRAULIC TILT & TRIM - W/ GAUGE Rated up to 130hp & smaller motors! Offers power tilt & trim, better boat handling, more speed, lower fuel consumption and no more back strain!! •6" set back to enhance boat stability and performance •For clamp-on or bolt-on motors without the need of an adapter •20˚ of trim & a total of 90˚ of tilt & trim •1/2" 6061 T6 extruded aluminum construction with S.S. fasteners •Electric hydraulic actuator rating: 7853 lbs. of thrust •Standard B.I.A. bolt hole pattern •Convenient adapter kit available for clamp-on motors •(4) Stainless steel motor mouting bolts included •Weight: 40 lbs.
ORDER NO. 205-13001
Mfr. No. 13001
For more information see: www.thmarine.com
Fits all CMC Power Lift Hydraulic Jack Plate Models. Fits all T-H Marine Hydro-JackerTM Hydraulic Jack Plate Models (2010 & later). • Gauge is sealed and drip proof and mounts in the dash of the boat • Provides safe and convenient height determination • Standard 2" gauge mount • Sending unit is completely sealed and waterproof • The up-down toggle switch is standard equipment • Safe and convenient position indicator • Dash mount gauge and toggle switch • Weatherproof gauge Note: The 6077 will only work on CMC Power-Lift if it is powered by an actuator in it. (7432 or 7050, circa 1997). If it is powered by a pump separate from a cylinder instead of an actuator, it will not work. ORDER NO. 205-06077 Mfr. No. 6077
