JACK PLATES
DOMETIC SEASTAR XTREME JACK PLATES - 400 HP RATING The SeaStar Xtreme Jackplates utilize high strength materials to be able to handle some of the strongest
engine on the water. The heavy duty frames are capable of handling engines up to 400 horsepower. Designed with speed and durability in mind the Xtreme Jackplates can adjust the engine height in just 8.5 seconds, even while the boat is moving at full power.
FEATURES:
• Xtreme jackplate is using high strength materials and is easily capable of handling up 400 horsepower engines
• Rapid hydraulic response in 8.5 seconds • Complete rigid engine support at full thrust • Easily moves engine up or down at full thrust • Smooth operation with composite bushings • Easy wrench access to engine bolts from the side • Compatible with all shallow water anchors • High output integrated actuator to lift and lower engines in all conditions • Environmentally sealed non-contact SmartStick position sensor kit
ORDER NO.
944-50400-X*
944-50600-X
944-50800-X
944-51000-X
944-51200-X
Mfr. No.
JP5040X
JP5060X
JP5080X
JP5100X
JP5120X
Mfr. No.
JP5040R
JP5060R
JP5080R
JP5100R
JP5120R
Setbacks
4" Setback Xtreme
6" Setback Xtreme
8" Setback Xtreme
10" Setback Xtreme
12" Setback Xtreme
JP5100R
Setbacks
4" Setback Standard
6" Setback Standard
8" Setback Standard
10" Setback Standard
12" Setback Standard
Xtreme Jack Plates
available for precise height information • Designed to maximize engine tilt with Dometic SeaStar steering cylinders • High visibility lift scale for quick glance operation • Integrated circuit breaker gives electrical protection right at the battery post • All hydraulic Jackplates come with basic rocker switch DK4020 • * NOTE: JP5040X requires adapter kit DK4600 for Power Pole® or Talon® anchor systems mounting
DOMETIC SEASTAR STANDARD JACK PLATES - 300 HP RATING The SeaStar Standard Jackplate is one of the sleekest and most durable engine jackplate available.
This essential performance accessory allows for higher speed, gains in fuel economy and the ability to run in shallow water. SeaStar Jackplate features sleek, bold styling that is redefining the look for jackplates. The SeaStar Jackplate is rated for 300 horsepower and it is designed to maximize engine tilt when used with SeaStar steering cylinders.
FEATURES:
• Our Standard Jackplate is easily capable of handling up to 300 horsepower gasoline engines
• Rapid hydraulic response in 8.5 seconds • Complete rigid engine support at full thrust • Easily moves engine up or down at full thrust • Smooth operation with composite bushings • Easy wrench access to engine bolts from the side • Compatible with all shallow water anchors • * NOTE: JP5040R requires adapter kit DK4600 for Power Pole®
or Talon® anchor systems mounting
SEASTAR JACK PLATE MOUNTING BOLT KITS
ORDER NO.
943-50400-R*
943-50600-R
943-50800-R
943-51000-R
943-51200-R
Standard Jack Plates
ORDER NO.
942-61250
942-61350
942-61450
942-61650
Mfr. No.
DK6125
DK6135
DK6145
DK6165
Description
Bolt Kit, 1/2-20 UNC 2.5" Length, 4 Pack
Bolt Kit, 1/2-20 UNC 3.5" Length, 4 Pack
Bolt Kit, 1/2-20 UNC 4.5" Length, 4 Pack
Bolt Kit, 1/2-20 UNC 6.5" Length, 4 Pack
For more information see: www.dometic.com
