Page 1276 - 2025 Parts & Accessories Catalogue

TRAILER JACKS & WINCHES
DELUXE & DELUXE PLUS TONGUE JACKS
Designed to withstand the wear & tear of frequent water exposure, CURT marine jacks are the jack of choice for the avid fisherman or boating enthusiast. Unlike any other jacks, CURT marine jacks are equipped with wheels, allowing for greater mobility & easier coupling of your trailer. Marine jacks also have a heavy-duty pull-pin that allows them to pivot on their mounting bracket to be out of the way for travel.
• Swivel bracket allows jack to fully swing up & out of the way for travel • Heavy-duty pull-pin keeps jack securely locked in place • 10" of vertical travel accommodates multiple ball heights • Bolt-on hardware included for secure mounting
• Protected by a durable zinc-plated finish
ORDER NO. Mfr. No. Load Travel Bracket Wheel Handle Retracted Extended HEAVY-DUTY
514-28113
514-28156
514-29451 2" x 20"
514-25003
514-28113
514-28116
514-28156
25003
28113
28116
28156
Capacity
1,000 lbs. 10"
1,200 lbs. 10"
1,500 lbs. 10"
1,500 lbs. 10"
Height Dia.
12-1/4" 6"
12-11/16" 6"
12-11/16" 8"
12-1/2" 6"
DUAL
Side-wind
Side-wind
Side-wind
Side-wind
Height
12-3/8"
12-1/2"
13"
12-5/8"
Height
22-3/8"
23-1/2"
24"
23"
Pull Pin
Included
Included
Included
Included
HAND WINCHES
CURT hand winches are designed to be mounted on a variety of trailers & are useful for boat trailers. CURT boat winches can also serve a number of other winch applications, though they are not designed for vehicle towing. • Constructed from high-strength, cold-forged steel • Equipped with a locking lever for increased safety
• Strong pinions eliminate gear-to-shaft bonding failures • Broached pinion shaft securely engages the pinion gear • Base features slotted screw holes for flexible mounting • Compatible CURT winch straps (#514-29450, 514-29451) or (#29007 SPECIAL ORDER)
ORDER NO.
514-29423
514-29433
514-29424
514-29435
514-29450
514-29451
514-29423
Mfr. No.
29423
29433
29424
29435
29450
29451
Capacity
900 lbs.
900 lbs.
1,200 lbs.
1400 lbs.
Style
Crank
Crank
Crank
Crank
514-29428
Handle Length/Material
6-1/2" Plastic Grip
6-1/2" Plastic Grip
7-1/2" Plastic Grip
7-1/2" Plastic Grip
Gear Hub Ratio Dia.
3.25:1 3/4"
3.25:1 3/4"
4.2:1 3/4"
4.2:1 3/4"
514-29435
Finish
Clear Zinc
Clear Zinc
Clear Zinc
Clear Zinc
Winch Strap (Included)
2" x 15'
514-29450
2" x 20'
514-29451
from 2" no-stretch nylon web.
2" x 20" Winch Strap w/ zinc-plated snap hook. Made from 2" no-stretch nylon web. Work load rating: 1,100 lbs. Break strength: 3,300 lbs.
2" x 15" Winch Strap w/ zinc-plated snap hook. Made Work load rating: 1,100 lbs. Break strength: 3,300 lbs.
1244
For more information see: www.curtmfg.com
