Page 806 - 2025 Parts & Accessories Catalogue

PROPANE FIREPLACE HEATERS
NEWPORT P9000 PROPANE FIREPLACE HEATER
The combustion process is completely isolated from the inside of the boat by the unique, direct vent design. A built-in blower provides good heat circulation. The heater is sold with all accessories needed including a stainless steel backing plate, 28" of flexible double stainless chimney and the deck fitting cap. NOTE: A propane hose, 11" WC regulator and fittings are needed and sold separately. • Easy to install • Stainless steel burner • Large ceramic glass viewing window with safety screen • Safe, direct-vent operation • Unaffected by motion or wind • Variable heat output and excellent thermal efficiency
NEWPORT P9000 PROPANE FIREPLACE HEATER
Dimensions:
Width: 8.5", Height: 14", Depth: 5.5", Weight: 22 lbs.
• Low fuel consumption • Compact design, with attractive appearance • Made of 304 stainless steel • No interier oxygen depletion • ABYC Approved for MARINE use only
Specifications: Mounting Backplate: Width: 8.375", Depth: 0.650", Height: 23" Fuel Consumption: 1lb. – 7hrs-LOW,20lb. – 140hrs 1lb. – 5 hrs - HIGH, 20lb. – 100 hrs Heat Output: Low: 3,200 BTU, High: 4,500 BTU
ORDER NO. 850-09000
Mfr. No. 00-NEW-P9000
NEWPORT P12000 PROPANE FIREPLACE HEATER
Dimensions:
Width: 10", Height: 16", Depth: 7.25", Weight: 25 lbs.
Specifications: Mounting Backplate: Width: 9.875", Depth: 0.650", Height: 23" Fuel Consumption: 1lb. – 5.5 hrs - LOW, 20lb. – 110 hrs 1lb. – 3.9 hrs - HIGH, 20lb. – 78 hrs ORDER NO. 850-12000 Heat Output: Low: 4,000 BTU, High: 5,500 BTU Mfr. No. 00-NEW-P12000
NEWPORT EXPLORER PROPANE FIREPLACE HEATER
Designed with an air-tight, direct vent system that ensures the combustion process is isolated from the living space. Includes a built-in blower for more rapid heat distribution. Packaged with all the necessary accessories, including a stainless steel backing plate, 28" flexible double stainless chimney, and a wind resistant deck fitting cap. Please note: A propane hose, 11" WC regulator, fittings, and chimney guard are required and sold separately. Dimensions:
Width: 10.75", Height: 17", Depth: 8.25", Weight: 22 lbs.
Specifications: Mounting Backplate: Width: 10.25”, Depth: 0.500", Height: 24.75" Fuel Consumption: 1lb. – 7hrs-LOW,20lb. – 140hrs 1lb. – 5 hrs - HIGH, 20lb. – 100 hrs Heat Output: Low: 3,200 BTU, High: 4,700 BTU
ORDER NO. 850-40000
Mfr. No. 00-NEW-EXPLORER
SERVICE PARTS FOR PROPANE FIREPLACE HEATERS
ORDER NO.
850-19000
850-19005
850-19030
Mfr. No.
19-000
19-005
19-030
Description
Chimney Flue Extension Kit, 2.5" x 28", Incl: Exterior 2.5" dia. Pipe & Interior 1.5" dia. Pipe, & Connection Clamps. 304 Stainless Steel Note: Maximum Chimney Length: 56"
Chimney Flue Extension Kit, 2.5" x 10", Incl: Exterior 2.5" dia. Pipe & Interior 1.5" dia. Pipe, & Connection Clamps. 304 Stainless Steel Note: Maximum Chimney Length: 56"
Chimney Flue Guard, 2.5" x 18", 304 Stainless Steel Note: Requires 20" clearance from guard to ceiling
Transformer Plug Converter, Convert from 110V AC to 12V DC
850-19211
19-211
850-19000 850-19005
850-19030
850-19211
Please contact our Technical Department for further information.
For more information see: www.dickinsonmarine.com
