TRIM TAB ACCESSORIES/COMPONENTS
#9
HYDRAULIC TRIM TABS ACCESSORIES
1. RESERVOIR
2. #10 x 1" SCREW
3. FILLER STACK
4. FILLER PLUG
5. MOUNTING BRACKET
6. LEXAN COVER
ORDER NO. 011-11111
ORDER NO. 011-00004
ORDER NO. 011-00005
ORDER NO. 011-00006
7. TYPE 25 THREAD CUTTING SCREW
8. MOTOR STRAP
9. SOLENOID VALVE
10. PUMP FACE
11. 1/8 PIPE TO 1/4" TUBE
12. HEX RETAINER
13. NUT w/FERRULE
14. HYDRAULIC TUBING
15. TUBE BEND CLIP
16. FEMALE ELBOW
17. BRASS PIPE NIPPLE
18. UPPER HINGE
19. #14 x 1-1/2" SCREW
20. CYLINDER
21. PISTON
22. PIN
23. LOWER HINGE .
ORDER NO. 011-00008
ORDER NO. 011-11352 (Red),
ORDER NO. 011-11351 (Green),
ORDER NO. 011-00012
ORDER NO. 011-00013
ORDER NO. 011-11250 (Per foot-WSL)
ORDER NO. 011-11250-20 (20 ft.)
ORDER NO. 011-11250-30 (30 ft.)
ORDER NO. 011-11250-50 (50 ft)
ORDER NO. 011-00015
ORDER NO. 011-00016
ORDER NO. 011-00017
ORDER NO. 011-00018
ORDER NO. 011-11010
ORDER NO. 011-00022
ORDER NO. 011-00023
24. WOODEN SHIM, AS REQUIRED (NOT INCLUDED IN SET)
25. BACKING PLATE
26. MOUNTING PLATES
27. HINGE PLATE
28. #10 x 1-1/4" SCREW ORDER NO. 011-00028
29. TRIM PLANE See Catalogue Page 942
30. 1/4 - 20 x 3/4" MACHINE SCREW
31. WIRE HARNESS STANDARD (LED DOWN CHANNEL IN BACK OF
RESERVOIR)
32. PLUG
33. NYLON HANGER
34. #4 x 1/2" SCREW
35. 20-AMP FUSE
36. FUSE HOLDER
ORDER NO. 011-10004
COMMON REPLACEMENT PARTS
HARDWARE PACK
ORDER NO. Mfr. No.
011-01170-1 H1170A
2ND HARDWARE PACK FOR DUAL ACTUATORS
ORDER NO. Mfr. No.
011-01170-2 H1170B
For more information see: www.bennetttrimtabs.com
