Page 980 - 2025 Parts & Accessories Catalogue

ELECTRIC TRIM TABS
STANDARD MOUNT TRIM TAB KITS - 12-VOLT
The most popular series. Ideal for most common style boats from center console fishing boats to cuddy cabin cruisers. Blades are constructed of 12 gauge (2.7mm) laser cut 304 stainless steel with 5/8" (1.6 cm) flared trailing edge & 1/8" (3.2 mm) diameter hinge pin. Upper & lower high impact corrosion proof mounting brackets with mechanical cable gland seal.
Kits Include:
(2) 12-Gauge stainless steel standard finish blades (2) Actuator with 6' leads and Deutsch connectors (Order #288-15054) (2) 20' Actuator extension wiring harness
(Order # 288-30133) (2) Upper mounting bracket with gland seal (Order # 288-15085) (2) Lower mounting bracket (Order # 288-50014 Lenco’s owner’s/installation manual Stainless steel mounting hardware * Sold in Retail Box * Switch kits sold separately
288-15000-1
EDGE MOUNT TRIM TAB KITS - 12-VOLT
ORDER NO.
288-15000-1
288-15001-1
288-15002-1
288-15003-1
288-15004-1
288-15005-1
288-15007-1
Mfr. No.
15000-101*
15001-101*
15002-101
15003-101
15004-101
15005-101
15007-101*
Boat Length
14' - 18'
16' - 25'
22' - 30'
26' - 40'
30' - 50'
34' - 65'
17' - 30'
L" x W"
Hinge Height
Min. Transom Height
14"
14"
14"
14"
14"
14"
14"
9" x 9" 2"
9"x12" 2"
9"x18" 2"
9"x24" 1"
9"x30" 1"
9"x36" 1"
12" x 12" 2"
Designed for boat applications where lower actuator mounting height is desirable. Fast response electric actuators for precise control. Fully submersible. All Plug & Play Deutsch connections. Blades are constructed of 12-gauge (2.7 mm) laser cut 304 stainless steel with 1" (2.5 cm) turned up edges & a 5 degree taper on both sides to the trailing edge, & 1/8" (3.2 mm) diameter hinge pin. Actuator mounts at the trailing edge of the blade giving it a 1/2" (1.3 cm) lower mounting height on 9" (22.9 cm) long blades & 3" (7.6 cm) lower mounting height on 12" (30.5 cm) long blades. All edges are turned up for added strength & style. Upper & lower high impact corrosion proof mounting brackets with mechanical cable gland seal.
Kits Include:
(2) 12-Gauge stainless steel standard finish blades (2) Actuator with 6' leads and Deutsch connectors (Order #288-15054) (2) 20' Actuator extension wiring harness (Order # 288-30133) (2) Upper mounting bracket with gland seal (Order # 288-15085) (2) Lower mounting bracket (Order # 288-50014 Lenco’s owner’s/installation manual Stainless steel mounting hardware * Sold in Retail Box * Switch kits sold separately
288-15016-1
Boat Mfr. No. Length
15015-101* 14' - 18' 15016-101* 17' - 30'
Min. Height Transom
Height 2" 11" 2" 11"
ORDER NO.
288-15015-1 288-15016-1
L" x W"
12" x 9" 12" x 12"
Hinge
For more information see: www.lencomarine.com
STANDARD PERFORMANCE TRIM TAB KITS - 12-VOLT
Designed specifically for performance. This system comes equipped with a thicker reinforced hinge & complemented with an electro-polished finish for added quality & protection. Blades are constructed of electro-polished 12 gauge (2.7mm) laser cut 304 stainless steel with 1" (2.5 cm) turned up edges & a 5 degree taper on the inside, heavy duty hinge with 1/4" (6.4 mm) diameter hinge pin. Upper & lower high impact corrosion proof mounting brackets with mechanical cable gland seal.
Each kit contains:
(2) 12-Gauge stainless steel electro-polished blades (2) Actuator with 6' leads and Deutsch connectors (Order #288-15054) (2) 20' Actuator extension wiring harness (Order # 288-30133) (2) Upper mounting bracket with gland seal (Order # 288-15085) (2) Lower mounting bracket (Order # 288-50014 Lenco’s owner’s/installation manual & Stainless steel mounting hardware * Switch kits sold separately
288-15035-1
SIZE DESCRIPTION
Boat Length
13' - 20' 16' - 26'
Hinge Height
2" 2"
Min. Transom Height
13.5" 13.5"
L W
= Length of Tab = Width of Hinge
Size description to be used with all charts
ORDER NO.
288-15034-1 288-15035-1
Mfr. No.
15034-101 15035-101
L" x W"
9" x 9" 9" x 12"
948
