CHAPTER 6.
EXAMPLES OF JUMBO LINE X-TRA SERIES. INTELLI-TUB®
SHIPPING DIMENSIONS AND WEIGHTS.

NOTE 1: FREIGHT COMPANIES CALCULATE AIR FREIGHT CHARGE FOR THE CRATED
TUBS BASED ON DIMENSIONAL WEIGHT.

NOTE 2: FOR FULL CONTAINER SHIPMENTS FREIGHT CHARGE IS CALCULATED BASED
ON THE ACTUAL ORDER.
AVERAGE 40 FOOT HC CONTAINER WILL COST YOU ABOUT $4,000.00. PRICE MAY VARY
SLIGHTLY DEPENDING ON THE” PORT OF ENTRY” WHERE CARGO IS UNLOADED AND
ENTERS A COUNTRY.

NOTE 3: LESS THAN CONTAINER LOAD WILL BE CALCULATED BASED ON THE WEIGHT
AND DIMS OF THE SHIPMENT.

# TUB MODEL TUB DIMENSIONS INCH/MM SAFETY STEP DIMENSIONS: TUBS ACTUAL WEIGHT CHARGEABLE

WIDTH X DEPTH X HEIGHT, WEIGHT VOLUME M³
L X W X H
WEIGHT: LBS/KGS

TUBS GROSS TUBS NET
W-T WEIGHT APP.
APP. CRATED
1 C-280 T-REM MA-08 CRATED: NOTE 1:
CARIBBEAN 106” x 50” x 80” DIMS/WEIGHT OF THE SAFETY STEPS ARE
PARADISE 2690mm x 1270mm x 2030mm THE SAME FOR ALL TUBS INCLUDED INTO:

LIMITED EDITION/ INSTALLED ON-SITE: “JUMBO LINE EXTRA” AND 1298 lbs/590kgs 847lbs/385 kgs 6.82m3
CARIBBEAN 100” x 42 ½” x 68” “JUMBO LINE PLATINUM”
PARADISE NOTE 2: USUALLY STEP IS PACKED INSIDE
2540mm. x 1080mm. x 1720mm. THE TUB WRAPPED INTO FOAM AND RUBBER.
2 C-280 T-REM MA-08 CRATED: THIS ALLOWS TO REDUCE FREIGHT COST.
EMERALD BAY 106” x 50” x 57” “42” x 29” x 26”
LIMITED EDITION 2690mm x 1270mm x 1448mm 1070mm x 740mm x 650mm 1272lbs/578 kgs 792lbs/360kgs 5m3
INSTALLED ON-SITE:
100” x 42 ½” x 52” BOXED FOR SHIPPING:
2540mm. x 1080mm. x 1321mm. 44lbs/20 kgs.
C-280 T-REM MA-08 CRATED: 1254lbs/570kgs 781lbs/355kgs 5m3
EMERALD BAY 106” x 50” x 57” NET WEIGHT: 26lbs./15kgs
2690mm x 1270mm x 1448mm VOL: 14.97f³/0.515m3
3
INSTALLED ON-SITE:
100” x 42 ½” x 51” NON-BOXED/ACTUAL SIZE:
2540mm. x 1080mm. x 1295mm. 40” x 27” x 16”
1020mm x 690mm x 410mm
