pu compressed-air hoses - straight

Compressed-air hoses made of
polyurethane (PU). These are
considerably lighter, more flexible and
more resistant to kinking than PVC
hoses.

Improved durability and performance
due to P.U.
• Increased working comfort and broader range
of applications.

Smooth inside hose surfaces prevent air
resistance and enable a high air flow
rate.
• No pressure drop and maximum utilization of
output of consumers.

High resistance to abrasion, sturdy cloth
lining and outstanding resistance to oil,
gasoline, dirt and UV.
• The temperature range is - 20°C to 60°C.
• Reduces costs and has a service life up to 10
times longer than that of PVC hoses.

Maximum operating pressure of 16 bar.
• Up to four times higher safety factor for the
user.

Please note:
• Fittings not included. • Not suitable for painting work.
• Suitable fittings listed in table. • Not suitable for especially moist environments
or use with water.
Hose dia. in mm Suitable Coupling Length PU Hose Suitable Plug-In Pack
Inside Outside Art. No. in m Art. No. Nipple Qty
Art. No.
0699 100 865
6.5 10.0 0699 100 765 10 0699 942 650
0699 101 865
10 0699 942 811 0699 100 880
8.0 12.0 0699 100 780 1
25 0699 942 812 0699 101 880
10 0699 942 115 0699 100 811
11.0 16.0 0699 100 711
25 0699 942 116 0699 101 811
