1/2” PREMIUM PNEUMATIC ANGLED IMPACT WRENCH

Powerful compressed air angled impact wrench with low
head height for working in constricted spaces.

High-quality hammer impact mechanism and cylinder with
7-vane motor.
For reliable, high performance and a long service life.

2-stage power setting with convenient right/left rotation
control.
Allowing efficient, user-friendly adjustment for the application required.

Ergonomically formed soft grip handle with sensitive
Technical Data:
trigger.
Type 1/2” Premium No cooling of the handle when working, good handling for optimal
Square drive 1/2” control.
Min. working torque 60 Nm
Max. working torque 190 Nm Very low head height of just 50 mm.
Max. releasing torque 244 Nm Ideal for use where access is restricted (e.g. engine compartments).
Sound-pressure level 97 dB
Vibration 43.5 m/s2
Weight of machine 1.8 kg
Min. hose inner diameter 10 mm
Air consumption 142 l/min
Connection thread 1/4 inch
Art. No. 5714 300 0
Pack Qty. 1
Important Accessories
Application Area Description Art. No. Pack
Assembly and disassembly of crankshaft, exhaust, installation and removal Qty.
of turbocharger, generator etc. Special Oil for Pneumatic Tools (1L) 0893 050 5
Grease Tube and Grs. Syringe Maintn. Set 0709 213 052
Note: Individual Grease Tube 0709 213 053 1
When the impact wrench is used regularly, a little oil should be added Inline Mini Mist Oiler 0709 861 055
daily through the compressed air, and approximately 2 strokes of gear
grease should be added monthly via the grease nipple.
More Power For Your Tool!
Fittings for 1500 Series
Description Art No.
1500 Stream Line Coupling 8 x 12mm 0699 101 780
1500 Stream Line Nipple 8 X 12mm 0699 101 880
PUR Hose 8x12mm 10m 0699 942 811
1500 Male Nipple 1/4" 0699 211 410
1500 Male Coupling 1/2" 0699 111 210

Fittings for 2000 Series
Description Art No.
2000 Stream Line Coupling 8 x 12mm 0699 100 780
2000 Stream Line Nipple 8 X 12mm 0699 100 880
0699 942 811
PUR Hose 8x12mm 10m
AUS. pub. 12/16 © 2000 Male Nipple 1/4" 0699 100 614
0699 100 312
2000 Male Coupling 1/2"
