Diagnosis - Diagnosis-fault diagnosis of electronic and electrical parts DI - 111

Error code list IN

Use the list below to help you find the reasons of failures. The number represents the order of failure reason
possibility. Check each part according to the order and replace it when necessary DI
DTC flash code DTC definition DTC check condition Failed part
EG
Right front solenoid valve

into the exhaust valve on the
power or other solenoid valve ● Solenoid valve wire TR
harness short circuit
harness
2+1 ● Ignition switch: ON
Right front solenoid valve ● Right front solenoid valve AX
open-circuit ● ABS ECU
FR
Right front solenoid valve
short-to-ground
ST
Left front solenoid valve into
the exhaust valve on the
power or other solenoid valve ● Solenoid valve wire BR
harness short circuit
harness
2+2 ● Ignition switch: ON
Left front solenoid valve ● Left front solenoid valve BW
open-circuit ● ABS ECU

Left front solenoid valve EL
short-to-ground

Right rear solenoid valve into
the exhaust valve on the
power or other solenoid valve ● Solenoid valve wire
harness short circuit
harness
2+3 ● Ignition switch: ON
Right rear solenoid valve ● Right rear solenoid valve
open-circuit ● ABS ECU

Right rear solenoid valve
short-to-ground

Left rear solenoid valve into
the exhaust valve on the
power or other solenoid valve ● Solenoid valve wire
harness short circuit
harness
2+4 ● Ignition switch: ON
Left rear solenoid valve ● Left rear solenoid valve

open-circuit ● ABS ECU

Left rear solenoid valve

short-to-ground

DI-111
