52-2 POWER STEERING - POWER STEERING SYSTEM

PRECAUTION

1 . Precaution on Power Steering System
52
(a) Stay no more than 5 seconds when the steering wheel is at the extreme position, or
it may damage the steering oil pump.
(b) Don't use the steering oil pump without power steering fluid, or it may damage the
steering oil pump.
(c) Pay attention to the service and maintenance of the power steering system.
2 . Maintenance Precaution on Power Steering System
(a) During service, wear necessary protective equipments to avoid potential accident.
(b) When servicing around any hot component, wait until it cools down before taking any
action, or it may lead to burn.
(c) Once the steering oil pipe is disconnected, seal it immediately to prevent impurities
from entering the pipe.
(d) When disassembling the steering system, don't touch the power steering fluid.
(e) Use the authorized steering oil and don't mix it with other products.

Steering oil: ATF-Ⅲ
(f) The steering oil in the steering gear shall be replaced after the first 3,000KM and every
20,000KM later. (Refer to "Chapter 52. Power steering - steering oil, replacement")
(g) Regularly check the level of the steering oil can, at least every 5,000KM. (Refer to
"Chapter 52. Power steering - power steering system, on-vehicle inspection")
(h) Regularly check the steering system, at least every 5,000KM.
• Check for loose or relaxed connection.
• Check the steering functioning.
