S.6 Generally (cont'd)

3. The following shall be given separately in metres stating the method of fixing if other than
that in clause S.16.1.e.

a. Sole plates.
b. Head.
c. Abutments to other finishings
d. Intersections.
e. Framings to openings.

4. Work to isolated columns shall be kept separate and so described stating the number of
columns.

5. Access panels shall be described and enumerated as extra over the work in which they
occur stating the method of securing.

Suspended ceilings, linings and support work (e.g. plasterboard, fibrous
tiles, etc.)

5.17 Generally

1. Particulars of the following shall be given:

a. Kind and quality of sheeting or tiles.
b. Size and thickness of sheeting or tiles.
c. Size and spacing of supports (including details of design module both for the
building and work in this section.)
d. Layout of joints. (If none stated the layout shall be at the Contractor's discretion.)
e. Treatment of joints. Lapped joints shall be given in the description.
f. Type, size and length of any hangers and brackets.
g. Nature of structure to which the brackets and hangers are fixed and, where to steel
framing, the wire and spacing of the members of such framing. Where the fixing of
brackets and hangers is obstructed by services, it shall be so described.
h. Method of securing brackets and hangers to structure.
j. Any services which are integrated with the lining including additional hangers,
framing, etc.

2. Linings shall be given in square metres. All necessary support work and accessories for
fixing shall be deemed to be included. No deduction shall be made for voids not
exceeding 0 50 m2.

3. Linings to ceilings, beams, upstands and sloping work shall each be so described giving
details of the slope (if any).

4. Access panels shall be described and enumerated as extra over the work in which they
occur stating the size

5. Trim at edges of linings shall be given in metres stating the material, size of section and
method and centres of fixing.

119
