casting machine

เครื่องหล่อ VC 1000, 3000 and 12000 casting machine

The Vacuum Pressure Casting Machine for large casting parts These machine are designed for: casting
Our large vacuum pressure casting machine are mostly used for • The automotive and components industries
precise castings in aluminium alloys. They are always the first choice • Rapid prototyping
for parts with complicated geometry or when the number of pieces • Orthopedic and medicine technologies
is not large enough for die-cast production.
• Machinery construction
VC 1000, 3000 and 12000 offer the best pre-conditions for high- • Tool making
quality castings in aluminium: the hydrogen content of aluminium • Sculptures
alloys may be adjusted by regulating the vacuum during melting.

Description Order#
VC 1000 01-701-980
VC 3000 01-701-981
VC 12000 01-701-982

VC 3000 V with large flask
VC 1000 with feeding chamber (option)
system and
window door
VC 12000

The Vacuum Pressure
Casting Machine

for large casting parts

*Liquid metal up to top level of the crucible
 = standard equipment  = optional
performance VC 1000 VC 3000 VC12000
power max. / electrical connection 25 kW 3x400 V 30 kW 3x400 V 40 kW 3x400 V
maximum temperature 1500° C 1500° C 1200° C
capacity  1,500 ccm = 4 kg Al  3,400 ccm = 9 kg Al  12,000 ccm = 30 kg Al
crucible volume ø 250 mm / 500 mm h ø 450 mm / 600 mm h ø 600 mm / 800 mm h
for use of flasks up to - ø 300 mm / 600 mm h -
optional up to
handling+control
16 temperature programs   
program control (100 programs)  VC 1000 V  VC 3000 V  VC 12000 V
automatic flask and chamber lift  VC 1000 V  VC 3000 V -
dual temperature control   
flask temperature measurement   
quality management
RS 232, diagnostic system, remote service   
data printer   
GSM modem   
other versions
available as granulating unit GU 1000 GU 3000 GU 12000
with magnesium kit   
