Installation Systems

Installation channel (A2 stainless steel) MQ-21-RA2 Installation channel (A4 stainless steel) MQ-41-R
Key applications and advantages Technical data Key applications and advantages Technical data
■ Recommended for installation in indus- Material Stainless steel, 1.4301 ■ Recommended for installation in indus- Material Stainless steel, 1.4404
trial atmospheres or areas with heavy composition (A2) - EN 10088 trial atmospheres or areas with heavy composition (A4) – EN 10088, AISI
316L
condensation condensation
■ Pipework ■ Pipework
■ Air ducts ■ Air ducts
■ C-profile with serrated edges ■ C-profile with serrated edges
■ Pre-marked dimensions make installa- ■ Pre-marked dimensions make installa-
tion, assembly and cutting easy tion, assembly and cutting easy

Ordering designation Height Length Material thickness Weight per metre length Approvals Sales pack Item number
quantity
MQ-21-RA2 6m 21 mm 6 m 2 mm 1450 g RAL-GZ 655-C 6 m 303991 Ordering designation Height Length Material thickness Weight per metre length Approvals Sales pack Item number
quantity

[
MQ-41-R 6m 41 mm 6 m 2 mm 2120 g RAL-GZ 655-C 6 m 303993

[

Installation channel (A2 stainless steel) MQ-41-RA2

Key applications and advantages Technical data
■ Recommended for installation in indus- Material Stainless steel, 1.4301 Installation channel (A4 stainless steel) MQ-52-R
trial atmospheres or areas with heavy composition (A2) - EN 10088
Key applications and advantages Technical data
condensation
■ Recommended for installation in indus- Material Stainless steel, 1.4404
■ Pipework
trial atmospheres or areas with heavy composition (A4) – EN 10088, AISI
■ Air ducts 316L
condensation
■ C-profile with serrated edges
■ Pipework
■ Pre-marked dimensions make installa- ■ Air ducts
tion, assembly and cutting easy
■ C-profile with serrated edges
■ Pre-marked dimensions make installa-
tion, assembly and cutting easy
Ordering designation Height Length Material thickness Weight per metre length Approvals Sales pack Item number
quantity
MQ-41-RA2 6m 41 mm 6 m 2 mm 2090 g RAL-GZ 655-C 6 m 303995
Ordering designation Height Length Material thickness Weight per metre length Approvals Sales pack Item number

[ quantity

MQ-52-R 6m 52 mm 6 m 2.5 mm 3000 g RAL-GZ 655-C 6 m 303997

[

Installation channel (A4 stainless steel) MQ-21-R

Key applications and advantages Technical data
■ Recommended for installation in indus- Material Stainless steel, 1.4404 Installation channel (A4 stainless steel) MQ-21 D-R
trial atmospheres or areas with heavy composition (A4) – EN 10088, AISI
316L
condensation Key applications and advantages Technical data
■ Pipework ■ Recommended for installation in indus- Material Stainless steel, 1.4404
■ Air ducts trial atmospheres or areas with heavy composition (A4) – EN 10088, AISI
condensation 316L
■ C-profile with serrated edges
■ Pre-marked dimensions make installa- ■ Pipework
tion, assembly and cutting easy ■ Air ducts
■ C-profile with serrated edges
■ Pre-marked dimensions make installa-
Ordering designation Height Length Material thickness Weight per metre length Approvals Sales pack Item number
quantity tion, assembly and cutting easy Installation Installation Systems Systems
MQ-21-R 6m 21 mm 6 m 2 mm 1470 g RAL-GZ 655-C 6 m 303989

[

Ordering designation Height Length Material thickness Weight per metre length Approvals Sales pack Item number
quantity
MQ-21 D-R 6m 41 mm 6 m 2 mm 2960 g RAL-GZ 655-C 6 m 303999

[

440 Visit the local website for more information on products and services www.hilti.group 441
