Installation Systems

Beam clamp (A4 stainless steel) MQT-R Ordering designation Anchor size Base plate clearance hole Wrench size Anchor length Package contents Sales pack Item number
quantity
Key applications and advantages Technical data AM20x1000 A4-70 M20 22 mm 30 mm 1000 mm 1x Threaded stud M20X1000 stnls. 5 pc 58688
■ For fastening MQ channels to steel Material Stainless steel, 1.4404 AM24x1000 A4-70 M24 26 mm 36 mm 1000 mm 1x Threaded stud M24X1000 stnls. 5 pc 58689
beams without drilling or welding (use composition (A4) – EN 10088, AISI
316L, Nut: A4-70 - DIN
only in pairs!)
EN ISO 3506-2
■ No drilling or welding neccessary
Material thickness 6 mm
■ Completely pre-assembled and suits all
standard T-beams Additional product Beam clamps always to
information be used in pairs

Ordering designation Thread - M Wrench size Tightening torque Weight Sales pack Item number Flat washer DIN 125 (A4 stainless steel)
quantity
MQT-21-41-R M10 17 mm 10 Nm 427 g 10 pc 304067 Technical data
Material
0 Stainless steel A4 – DIN

composition
EN ISO 7089

MQT-52-82-R M10 17 mm 20 Nm 471 g 10 pc 304068
0

Ordering designation Inside diameter - DI Outside diameter - DA Cross section thickness - s Weight Sales pack Item number

quantity
A 8,4/16 A4 8.4 mm 16 mm 1.6 mm 2 g 50 pc 58622
Drilled plate (A4 stainless steel) MQZ-L-R A 10,5/20 A4 10.5 mm 20 mm 2 mm 3 g 50 pc 58042
',
Key applications and advantages Technical data A 13/24 A4 13 mm 24 mm 2.5 mm 5 g 50 pc 58041
6
■ For wall, ceiling or floor attachment of Material Stainless steel, 1.4404 A 17/30 A4 17 mm 30 mm 3 mm 10 g 25 pc 387989
angles, connectors or brackets composition (A4) – EN 10088, AISI '$
316L A 21/37 A4 21 mm 37 mm 3 mm 15 g 25 pc 387990
■ For fastening metric threaded parts to
MQ channel
A 25/44 A4 25 mm 44 mm 4 mm 30 g 25 pc 387991
■ Matches the MQ channel system
perfectly
■ Suitable for MQ installation channels
and brackets

Ordering designation Hole diameter - D Weight Sales pack Item number Hexagon nut (A4 stainless steel)
quantity
MQZ-L9-R 9.5 mm 90 g 20 pc 304071 Technical data
Material Stainless steel A4-70

composition
MQZ-L11-R 11.5 mm 82 g 20 pc 304072
'
MQZ-L13-R 13.5 mm 80 g 20 pc 304073

Economical anchor rod for injection (A4 stainless steel),AM A4-70
Technical data
Anchor type Metre rods Installation Installation Systems Systems
Ordering designation Thread - M Height - H Wrench size - W Weight Sales pack Item number
Head configuration Externally threaded
quantity
Material Stainless steel A4-70 M8 A4-70 M8 7 mm 13 mm 5 g 50 pc 52460
composition
M10 A4-70 M10 8 mm 17 mm 11 g 50 pc 52461
PROFIS software No
0
Material, corrosion Steel, stainless M12 A4-70 M12 10 mm 19 mm 16 g 50 pc 52462
+
M16 A4-70 M16 13 mm 24 mm 31 g 25 pc 52463
Ordering designation Anchor size Base plate clearance hole Wrench size Anchor length Package contents Sales pack Item number :
quantity M20 A4-70 M20 16 mm 30 mm 54 g 25 pc 387992
AM8x1000 A4-70 M8 9 mm 13 mm 1000 mm 1x Threaded stud M8X1000 stnls. 10 pc 58666
M24 A4-70 M24 19 mm 36 mm 96 g 25 pc 387993
AM8x2000 A4-70 M8 9 mm 13 mm 2000 mm 1x Threaded stud M8X2000 stnls. 10 pc 414778
AM10x1000 A4-70 M10 12 mm 17 mm 1000 mm 1x Threaded stud M10X1000 stnls. 10 pc 58670
AM10x2000 A4-70 M10 12 mm 17 mm 2000 mm 1x Threaded stud M10X2000 stnls. 10 pc 414779
AM12x1000 A4-70 M12 14 mm 19 mm 1000 mm 1x Threaded stud M12X1000 stnls. 5 pc 58671
AM12x3000 A4-70 M12 14 mm 19 mm 3000 mm 1x Threaded stud M12X3000 stnls. 5 pc 58709
AM16x1000 A4-70 M16 18 mm 24 mm 1000 mm 1x Threaded stud M16X1000 stnls. 5 pc 58683

446 Visit the local website for more information on products and services www.hilti.group 447
