P. 39
24. Power up the server (on page 17).
25. Install and lock the tower bezel ("Install the tower bezel" on page 18).
Drive options
When adding drives to the server, observe the following general guidelines:
• The system automatically sets all device numbers.
• If only one drive is used, install it in the bay with the lowest device number.
Drives must be the same capacity to provide the greatest storage space efficiency when drives are
grouped together into the same drive array.
Installing a hot-plug drive
CAUTION: To prevent improper cooling and thermal damage, do not operate the server
unless all bays are populated with either a component or a blank.
To install the component:
1. Remove the drive blank.
2. Prepare the drive.
Hardware options installation 39
