Conical sieve mill ConiWitt
ConiWitt 150-200-250 TC-Lab 09/10 Product Range_2
•
2 cm - 150 μm • 100 to 3000 kg/h
Modular compact design
Vertical uninterrupted product flow
Head interchangeable between the ConiWitt-150 and the ConiWitt-200,
HammerWitt-Lab head as option
Customization of inlet/outlet for complete integration

Oscillating sizing and sieving mill MF-Line
MF-3 MF-6 MF-8 MF-Lab
•
•
•
5 cm - 250 μm • up to 2000 kg/h
Ideal mill for heat-sensitive or difficult products (dry/moist)
Gentel sieving of the product due to the constant speed and force
applied by the oscillating motion of the rotor
Vast choice of different types of sieves and rasps
Sieve, rotor and screen support can be easily installed and removed
through the large front-swinging door

Lump breaker
CC-310 CCD-450
•
30 cm - 2 cm • 3000 kg/h to 4000 kg/h
Perfect for coarse milling of hard products such as slabs,
ribbons and lumps
Available in single-rotor (3000 kg/h) and dual-rotor
(4000 kg/h) models
Pharmaceutical and food industry models also available
Compact height, easy integration for in-line applications

Delump, sizing and sieving mill DelumpWitt
60 cm - 500 μm • up to 9000 kg/h
Delumping, fine milling, and dosing with one single equipment
Blocks from 60 x 30 x 20 cm can be processed in one step
to free-flowing powder
The milling head can be swivelled out from the pregrinder in a few easy steps.
Using tri clamp connetions.
The “Error Proof System” guarantees correct installation
and removal of rotor and sieve

Use only original Frewitt replacement and spare parts.
Using other than original Frewitt parts voids the ATEX certification and can lead to hazardous
situations, which in turn can result in an explosion or an injury.

Our specialists and our laboratory are at your disposal
