TOOL AND EQUIPMENT
LEGEND

The tools and equipment, designated by numer-
als on the floor plan in Figure 12, are as follows:
1. Acetylene and oxygen tanks
2. Band saw

3. Barrel vise
4. Belt/disc sander 1”
5. Belt/disc sander 6”
6. Bench drill press (with support cradle) Figure 13: Adjusting vernier on a lathe.
7. Bench grinder
8. Bluing tanks
9. Business computer terminal
33. Refrigerated storage
10. Central vacuum
34. Shipping equipment and scales
11. Checkering cradle
35. Spindle grinder/polisher
12. Cyanide furnace
36. Stock duplicator
13. Drill press (floor model)
37. Stock vise
14. Drying cabinet
38. Supply storage
15. Engine lathe (50” centers)
39. Surface grinder
16. Exhaust fan
40. Tandem drill presses
17. File storage
41. Tig welder
18. Foredom grinder (overhead)
42. Time clock
19. Heavy-duty bench vise
43. Tool-and-cutter grinder
20. High-speed wood mill
44. Toolroom lathe
21. Hard wheel belt sander 2”
45. Tool storage
22. Holding area rack
46. Variable-speed drill press
23. Inventory control computer terminal
47. Variable-speed vertical mill
24. Loading press (metallic)
48. Vented hood
25. Loading press (progressive)
49. Vented bluing booth barrier
26. Machinist’s tool chest
50. Vented spray booth barrier
27. Pedestal buffer
51. Vertical/horizontal mill
28. Pedestal grinder
52. Vertical belt sander 2”
29. Powder measure
53. Vibrator/polisher
30. Powder scales
54. Water supply
31. Radial arm router
55. Wood lathe
32. Recordkeeping computer
