MECHANICAL REMOTE CONTROLS

REMOTE CONTROL ATTACHING KIT RIGGING HOSE MECHANICAL REMOTE CONTROLS

880093A 2 32-859055 5
Fits 2002‑2006 Mercury 40 hp 4‑Stroke Bigfoot and 50/60 hp 4‑Stroke EFI Replacement Hose, 2 in. dia. x 2.3 threads per inch, furnished in a 5 ft. length.
outboards (USA‑0T409000‑1B344306, BEL‑0P401000‑0P515896, Fits various Mercury / Mariner V‑6 outboards. See application chart for specific
CHN‑1C000001‑1C050251). engine models.
32-859055 50
OUTBOARD RIGGING HOSE KIT Replacement Hose, furnished in a 50 ft. bulk length that can be cut to required
length.
Used to enclose remote harness, hoses, cables, etc. between engine Fits various Mercury / Mariner V‑6 outboards. See application chart for specific
cowl and boat transom. engine models.
Priced individually, sold @ multiples of 2
RIGGING TUBE KIT COWL FITTING

8M0149598
Rigging Tube kit includes 5 ft length (2 in. dia. x 2.3 threads per inch) tube that
screws into the fitting coming out of the 3.4L V6 and 4.6L V8. Included in the kit is
the plastic transom fitting that screws to the other end of the tube and can be
fastened to the boat. Also included are the 3 different grommets that may be
needed for different installations with the 3.4L or 4.6L engine platforms (CMS
mech, CMS DTS, and AMS Verado).
3.4L and 4.6L outboard engines
32-825191A03 875266A 2
Rigging Tube kit includes 5 ft length (2 in. dia. x 2.3 threads per inch) tube that Used on engine end of rigging hose.
screws into the fitting coming out of the Verado. If OptiMax engine, requires the
use of the clamp to attach to fitting coming out of engine. Included in the kit is Fits various Mercury / Mariner V‑6 outboards. Furnished standard with the engines
plastic transom fitting that screws to the tube and can be fastened to the boat. beginning with model year 2,000. See application chart for specific engine models.
2005 and newer Verado engines as well as all Opti Max engines COWL FITTING
32-8M0088822
Rigging Tube kit includes 5 ft length (2 in. dia. x 2.3 threads per inch) tube that
screws into the fitting coming out of the engine. Includes new grommet
8M0075942 that is used when installing rigging tubes. Remove existing grommet
from cowl and replace with this grommet..
New 75‑115 4 stroke
32-8M0062693
Rigging Tube kit includes 5 ft length (2 in. dia. x 2.3 threads per inch) tube that
screws into the fitting coming out of the engine. Includes new grommet
8M0061160 that is used when installing rigging tubes. Remove existing grommet
from cowl and replace with this grommet..
Used on 150 EFI 4‑Stroke engine only
GROMMET - INGRESS 8M8027677
Used on engine end of rigging hose.
Fits various Mercury / Mariner V‑6 outboards. Furnished standard with the engines
beginning with model year 2,000.

8M0062583
Special Grommet used with Rigging Kits
150 HP 4 Stroke only

Not all parts listed are available for the European, C.I.S., Africa and Middle East Markets. 501
For more information, please contact your local Mercury, Mariner, MerCruiser or
Quicksilver Office.
